Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 4800 x 1400 x 762 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Central cable trough length | 4200 mm | |
| Central cable trough width | 150 mm | |
| Per-seat user space allocation | 600 mm | |
| Under-table seated leg clearance height | 690 mm | |
| Base panel thickness | 50 mm | |
| Power/data module cutout size | 272 x 132 mm | |
| Edge overhang from base perimeter | 80 mm | |
| Radius of rounded table corners | 50 mm | |
| Curved base section protrusion depth | 120 mm | |
| Trim accent strip thickness | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load capacity | 260 kg | |
|---|---|---|
| Seating capacity | 16 people | |
| Product net weight | 227 kg | |
| Surface scratch resistance rating | 3000 cycles | |
| Edge impact resistance | 20 N | |
| Finish moisture resistance | Grade B | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25mm MFC (melamine faced chipboard) | |
|---|---|---|
| Tabletop surface finish | Matte light oak thermally fused laminate | |
| Edge banding | 2mm impact-resistant PVC | |
| Base construction | 38mm laminated engineered wood panels | |
| Accent trim | Thermofused laminate matching tabletop finish | |
| Cable management components | Steel trough with nylon brush grommets |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | Full-length recessed central trough with brush openings | |
|---|---|---|
| Embedded power/data modules | Evenly spaced recessed units with AC, USB-A, USB-C, RJ45, HDMI ports | |
| Fixed height design | Non-adjustable 762mm work surface | |
| Closed panel base design | Full-width sculpted base with hollow internal raceway |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate boardrooms | Large 16-seat capacity supports executive leadership and board meetings | |
|---|---|---|
| Large conference meeting rooms | Integrated power/data connectivity supports hybrid meeting presentations and device charging |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture – Strength, durability and safety for non-domestic tables, applicable for commercial office use | |
|---|---|---|
| EN 14073-2:2004 | Office furniture – Storage and work surfaces, safety requirements applicable to work surface edges |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for office tables, applicable for strength, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for commercial grade environmental performance | |
| ANSI/BIFMA X5.9-2019 | Standard for storage and worksurface power/data units, applicable to integrated ports |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop and panel construction | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to MFC tabletop and base substrates | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture, applicable for indoor air quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop and panel construction; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable to MFC tabletop and base substrates; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture, applicable for indoor air quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
