Dark Woodgrain Rectangular Conference Meeting Table with Central Cable Channel and Geometric Angled Legs (model CONF-GEO-2400-DW) is listed under Conference Table, with overall dimensions of 2400 × 1200 × 760 mm and main material of Particle‑board (PB). Load capacity: 160 kg. Certifications: modern,geometric,design,integrated,cable,management,rectangular,boardroom,table. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 1200 x 760 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Central cable channel width | 150 mm | |
| Under-table knee clearance height | 690 mm | |
| End outrigger leg base span | 600 mm | |
| Central support column cross-section | 150 x 150 mm | |
| Tabletop edge profile | 2 mm reverse bevel | |
| Adjustable foot pad height adjustment | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Evenly distributed static tabletop load capacity | 160 kg | |
|---|---|---|
| Total seating capacity | 8 people | |
| Surface abrasion resistance rating | 2000 cycles | |
| Surface stain and scald resistance | Grade B | |
| Net product weight | 114 kg | |
| Structural wobble rating | ≤1 mm lateral deflection at 100kg edge load | |
| Limited commercial warranty | 5 years | |
| Seating capacity per long side | 4 people | |
| End seating capacity | 2 people | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 25mm E1 grade engineered wood with dark woodgrain finish | |
|---|---|---|
| Central cable channel | Matte silver anodized aluminum flip-top tray | |
| End outrigger legs | 2mm thick light gray powder-coated steel trapezoidal supports | |
| Central support column | 2mm thick square powder-coated steel vertical column | |
| Undersurface bracing | 1.5mm thick steel cross-bracing connecting all supports | |
| Leveling feet | Nylon base with M10 steel threaded adjusters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central cable management | Full-length flip-open aluminum tray routing power/data cables under tabletop | |
|---|---|---|
| Cable routing through supports | Internal cable channel in central column for concealed wire runs | |
| Floor leveling | Adjustable nylon foot pads compensate for uneven office flooring | |
| Modular power compatibility | Pre-drilled mounting points for power/USB/HDMI/data modules in central channel |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Corporate boardrooms and executive meeting rooms | |
|---|---|---|
| Secondary application space | Open-plan office collaborative meeting zones |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture seating dimensional compatibility for matching conference chairs | |
| EN 15372:2016 | Furniture strength, durability and safety for non-domestic tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard for structural performance and durability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and corporate responsibility |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to tabletop and structural components | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to engineered wood tabletop core | |
| GB 18584-2001 | Indoor decoration material limit of formaldehyde emission for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to tabletop and structural components; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to engineered wood tabletop core; 3. GB 18584-2001: Indoor decoration material limit of formaldehyde emission for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
