Large Rectangular Conference Table with Central Cable Management and Box Bases (model CF-3600-BOX-DUAL-PORT) is listed under Conference Table. Dimensions: 3600 × 1400 × 750 mm. Materials: Dark brown woodgrain high-pressure laminate over engineered-wood substrate; exact grade and board core need supplier BOM confirmation.. Load capacity: 200 kg. Product Features: rectangular,table,dual,box-base,support,cable,management,modern. This page consolidates 6 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | XIANGSHI | Model | CF-3600-BOX-DUAL-PORT |
| Overall dimensions (W × D × H) | 3600 × 1400 × 750 mm | Power module cutout | 260 x 130 mm |
| Finished Top Thickness | 45 mm | Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
| Seating capacity | 12 persons | Distributed top load capacity | 200 kg |
| Point load at power-module area | 30 kg | Base static stability load | 400 kg |
| Product net weight | 165 kg | Top surface uniform load | 120 kg/m² |
| Drawer-slide or moving-part cycles | Not applicable | Suggested maximum display weight | 25 kg |
| Top Static Load Reference | 150 kg uniformly distributed | Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
| Work surface | Dark brown woodgrain high-pressure laminate over engineered-wood substrate; exact grade and board core need supplier BOM confirmation. | Edge profile | Matched laminate or PVC edge band with softly radiused corners; 2 mm edge thickness is the procurement target. |
| Cable and power covers | Two rectangular access covers, one white socket-style plate and one dark cover, set flush into the rail. | Support bases | Dark gray matte panel-constructed box bases with vertical face seams and lower plinth; substrate finish needs BOM confirmation. |
| Leveling system | Concealed adjustable glides within the plinth, 12 mm shank and 15 mm adjustment recommended for installation. | Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
| Central cable routing | Cables route through a continuous recessed center rail and two access ports between opposing seating positions. | Power and data integration | One tabletop module position supports power, USB, HDMI, or network sockets; socket count is configurable before order. |
| Removable access covers | Flush lift-out or hinged rectangular covers expose cable runs without dismantling the tabletop. | Fixed support configuration | Twin enclosed box bases stabilize the long top and leave the central seating perimeter open for chairs and legs. |
| Main top carton dimensions | 1850 x 760 x 120 mm per carton | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Package Dimensions | 2100× 1100× 300 mm |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | Reference Packaging Volume | 0.55 m³/set |
| Boardroom meeting room | Suits a 12-person executive boardroom where laptops, documents, and conferencing cables are shared across a central rail. | Director or negotiation room | Dark woodgrain top and enclosed gray bases fit premium management, client meeting, or contract-negotiation interiors. |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3600 × 1400 × 750 mm | |
|---|---|---|
| Power module cutout | 260 x 130 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Seating capacity | 12 persons | |
|---|---|---|
| Distributed top load capacity | 200 kg | |
| Point load at power-module area | 30 kg | |
| Base static stability load | 400 kg | |
| Product net weight | 165 kg | |
| Top surface uniform load | 120 kg/m² | |
| Drawer-slide or moving-part cycles | Not applicable | |
| Suggested maximum display weight | 25 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | Dark brown woodgrain high-pressure laminate over engineered-wood substrate; exact grade and board core need supplier BOM confirmation. | |
|---|---|---|
| Edge profile | Matched laminate or PVC edge band with softly radiused corners; 2 mm edge thickness is the procurement target. | |
| Cable and power covers | Two rectangular access covers, one white socket-style plate and one dark cover, set flush into the rail. | |
| Support bases | Dark gray matte panel-constructed box bases with vertical face seams and lower plinth; substrate finish needs BOM confirmation. | |
| Leveling system | Concealed adjustable glides within the plinth, 12 mm shank and 15 mm adjustment recommended for installation. | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central cable routing | Cables route through a continuous recessed center rail and two access ports between opposing seating positions. | |
|---|---|---|
| Power and data integration | One tabletop module position supports power, USB, HDMI, or network sockets; socket count is configurable before order. | |
| Removable access covers | Flush lift-out or hinged rectangular covers expose cable runs without dismantling the tabletop. | |
| Fixed support configuration | Twin enclosed box bases stabilize the long top and leave the central seating perimeter open for chairs and legs. |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Main top carton dimensions | 1850 x 760 x 120 mm per carton | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Boardroom meeting room | Suits a 12-person executive boardroom where laptops, documents, and conferencing cables are shared across a central rail. | |
|---|---|---|
| Director or negotiation room | Dark woodgrain top and enclosed gray bases fit premium management, client meeting, or contract-negotiation interiors. |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
