Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 4880 x 1220 x 760 mm | |
|---|---|---|
| tabletop thickness | 44 mm | |
| central cable channel width | 200 mm | |
| central cable channel length | 3900 mm | |
| leg/panel support width | 220 mm | |
| floor contact base depth per support | 450 mm | |
| continuous modesty panel height | 450 mm | |
| seated leg clearance height | 660 mm | |
| seated leg clearance depth | 1070 mm | |
| rounded corner radius | 80 mm | |
| power module spacing along channel | 1220 mm | |
| table edge overhang per side | 75 mm | |
| leveling foot adjustment range | 10 mm | |
| power module cutout size | 200 x 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| seating capacity | 16 persons | |
|---|---|---|
| distributed static tabletop load capacity | 1000 kg | |
| net product weight | 196 kg | |
| surface scratch resistance rating | Class 2 commercial grade | |
| power outlet rating per module | 12A 125V AC | |
| USB port charging output per module | 2.1A 5V | |
| power supply cord length | 2.4 m | |
| commercial warranty period | 3 years | |
| static load per leg support | 250 kg | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop core | 44mm thick MDF particleboard composite with honeycomb reinforcement | |
|---|---|---|
| tabletop surface | Thermally fused light oak grain melamine laminate | |
| tabletop edging | 2mm thick impact-resistant beige ABS matching base finish | |
| base and support panels | 25mm thick E1 grade engineered wood with matte beige PU lacquer | |
| cable channel cover | 1.5mm thick matte beige ABS plastic | |
| power module housing | Flame-retardant ABS plastic with brushed stainless steel trim |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| central cable management | Full-length recessed trough with removable cover routes power/AV/network cables | |
|---|---|---|
| integrated power/data modules | Four evenly spaced flush inset modules with AC outlets, USB charging, HDMI and RJ45 ports | |
| continuous modesty panel | Full-span panel between legs conceals cables and seated leg area | |
| floor leveling adjustment | Threaded glides on each leg base adjust to eliminate wobble on uneven floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| corporate boardrooms | Formal 16person meeting space with integrated AV/power for executive sessions | |
|---|---|---|
| large conference centers | Multi-purpose meeting rooms requiring modular power access for hybrid meetings |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Non-domestic furniture – Strength, durability and safety requirements for tables | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface resistance to abrasion and scratching | |
| EN 60950-1:2006 | Safety standard for integrated information technology equipment power modules |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | American national standard for office table performance and durability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Sustainability standard for business and institutional furniture, applicable for material emissions |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood table structure | |
|---|---|---|
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, static load and durability requirement reference | |
| GB 20210-2006 | Fire safety requirements for office furniture upholstery and panel materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood table structure; 2. GB/T 10357.1-2013: Furniture mechanical performance test for tables, static load and durability requirement reference; 3. GB 20210-2006: Fire safety requirements for office furniture upholstery and panel materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
