| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 3000 x 1200 x 750 mm | |
|---|---|---|
| tabletop thickness | 25 mm | |
| edge radius | 3 mm | |
| central cable channel width | 180 mm | |
| pedestal dimensions | 650 x 400 x 725 mm | |
| pedestal offset from table end | 250 mm | |
| under-table knee clearance height | 680 mm | |
| under-table longitudinal clearance between pedestals | 1500 mm | |
| seating clear width per place setting | 750 mm | |
| ABS edge banding thickness | 2 mm | |
| integrated cable access cutout size | 120 x 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| distributed static tabletop load capacity | 136 kg | |
|---|---|---|
| net product weight | 95 kg | |
| surface abrasion resistance | 2000 cycles | |
| finish moisture resistance rating | Level 2 | |
| levelling foot adjustment range | 10 mm | |
| warranty period | 5 years | |
| seating capacity per long side | 4 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop substrate | E1 grade medium density fiberboard | |
|---|---|---|
| tabletop finish | Dark walnut wood grain melamine laminate | |
| edge trim | 2mm thick ABS plastic edge banding | |
| pedestal structure | Engineered wood panel with matte light taupe PU coating | |
| cable channel cover | Matte light grey rigid plastic panel | |
| internal hardware | Zinc-plated steel connector bolts and cam locks |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| central cable management | Full-length recessed under-top cable tray with 3 access cutouts | |
|---|---|---|
| floor levelling adjustment | Threaded adjustable feet at each pedestal base | |
| modular power/data compatibility | Pre-cut openings fit standard conference table power/USB/HDMI modules | |
| assembly installation | Knockdown design with two pedestal bases attached to pre-finished top |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| corporate boardroom | 8-person meeting capacity for executive team discussions and client presentations | |
|---|---|---|
| open office collaborative zone | Integrated cable management supports laptops, video conferencing and presentation devices |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office work tables safety and structural strength test methods | |
|---|---|---|
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion and dry heat |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products structural performance and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for table structural stability | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for table structural stability; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
