Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 3600 x 1500 x 760 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Tabletop overhang | 50 mm | |
| Central cable raceway width | 150 mm | |
| End panel radius | 150 mm | |
| Base panel thickness | 36 mm | |
| Under-table knee clearance height | 670 mm | |
| Edge trim thickness | 2 mm | |
| Seating per long side | 5 | |
| Power module cutout size | 200 x 120 mm | |
| Base plinth height | 50 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed tabletop static load | 136 kg | |
|---|---|---|
| Product net weight | 210 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Surface moisture resistance rating | Level 2 | |
| Connector static shear strength | 1000 N per fitting | |
| Warranty period | 10 years | |
| Available finish variants | 2 | |
| Total seating capacity | 12 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | E1 grade particleboard | |
|---|---|---|
| Tabletop surface | Thermofused melamine laminate | |
| Base construction | 36mm thick MDF panels | |
| Edge detailing | 2mm PVC edge banding | |
| Cable raceway lining | Nylon brush strips | |
| Assembly hardware | Zinc-plated steel cam locks and bolts |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Full-length central recessed raceway | |
|---|---|---|
| Power module access | Four integrated cutout positions | |
| Cable pass-throughs | Dual grommet openings in raceway | |
| Assembly configuration | Knockdown sectional assembly |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Applicable space | Corporate boardrooms and formal executive meeting rooms | |
|---|---|---|
| Intended users | Enterprise facilities, commercial office procurement teams |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
