Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 800 x 750 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Base floor contact diameter | 450 mm | |
| Pedestal shaft minimum diameter | 60 mm | |
| Undertable knee clearance height | 710 mm | |
| Undertable leg clearance radius | 350 mm | |
| Tabletop overhang past base edge | 175 mm | |
| Floor clearance under base flange | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 18 kg | |
|---|---|---|
| Static tabletop load capacity | 50 kg | |
| Recommended seating capacity | 2 persons | |
| Stability lateral tip load | 15 kg | |
| Surface scratch resistance | 300 cycles | |
| Surface heat resistance | 80 °C | |
| Surface dry heat resistance | 80 °C | |
| Finish adhesion durability | 1000 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm MDF substrate | |
|---|---|---|
| Tabletop finish | White polyurethane matte lacquer coating | |
| Pedestal shaft | Molded ABS plastic with white painted finish | |
| Floor base plate | Die-cast aluminum composite with white powder coated finish | |
| Tabletop to pedestal connection | Steel M8 mounting bolt set | |
| Base underside floor protection | 3mm thick EVA felt pads | |
| Edge profile | 2mm rounded safety edge | |
| Core moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Seating access | 360 degree unobstructed access around central pedestal | |
|---|---|---|
| Floor protection | Pre-applied anti-scratch felt pads on base underside | |
| Surface maintenance | Non-porous sealed finish allows wipe-clean maintenance | |
| Assembly requirement | Two-point knockdown assembly | |
| Weight distribution | Centered pedestal design evenly distributes load across base plate | |
| Color consistency | Uniform white finish across tabletop, stem and base | |
| Stability performance | Flared weighted base design reduces wobble on level hard floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 870 x 870 x 130 mm | |
| Gross shipping weight | 21 kg | |
| Shipping volume per unit | 0.1 CBM | |
| assembly time | 20 minutes | |
| 20ft GP container loading quantity | 220 units | |
| 40ft HQ container loading quantity | 540 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
| Small apartment dining nook | 800mm compact footprint fits in studio apartments or small kitchen spaces, accommodates two diners without excessive floor space usage | |
|---|---|---|
| Breakfast or casual dining area | Standard 750mm dining height pairs with standard dining chairs for casual meal service in kitchen or open plan living spaces | |
| Office breakout or waiting area | Sleek modern white finish works in contemporary office lounge spaces for guest seating, casual meetings or refreshment service | |
| Balcony or covered outdoor seating | Lightweight sealed construction can be used in covered outdoor patios, not recommended for permanent exposure to direct rain or extreme weather | |
| Cafe or boutique seating | Compact size works for small bistro or cafe seating arrangements, paired with molded side chairs for a minimalist mid-century modern aesthetic | |
| Temporary event seating | Lightweight knockdown construction allows easy transport and setup for pop-up events, showrooms or temporary display use | |
| Casual kitchen breakfast area | 750mm standard dining height pairs with 450mm seat height dining chairs for daily meal service in kitchen or open-plan living dining zones | |
| Office breakout refreshment area | Minimalist white matte finish complements contemporary office lounge spaces, suitable for guest refreshment service and small informal 2-person meetings |
EU Market Access Requirements* EN Standards
| Domestic table safety recommendation | EN 12521:2015 | |
|---|---|---|
| Surface resistance recommendation | EN 15187:2007 | |
| Surface heat resistance recommendation | EN 15187:2007 | |
| Surface impact recommendation | EN 15185:2011 |
Standards applicable to China-market projects
| Table stability recommendation | GB/T 3324 | |
|---|---|---|
| Surface finish recommendation | GB/T 4893.4 | |
| Formaldehyde emission recommendation | GB 18584 | |
| Structural strength recommendation | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Table stability recommendation: GB/T 3324; 2. Surface finish recommendation: GB/T 4893.4; 3. Formaldehyde emission recommendation: GB 18584; 4. Structural strength recommendation: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
