Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 1200 × 750 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Pedestal base top diameter | 350 mm | |
| Pedestal base bottom diameter | 580 mm | |
| Pedestal base height | 720 mm | |
| Under-table knee clearance height | 680 mm | |
| Tabletop overhang from pedestal edge | 310 mm | |
| Floor contact footprint diameter | 580 mm | |
| Edge radius | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight range | 45 kg | |
|---|---|---|
| Static tabletop load capacity | 150 kg | |
| Recommended seating capacity | 4 persons | |
| Pedestal base static floor load | 260 kg/m² | |
| Surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 50 N | |
| Vertical stability load | 75 kg | |
| Finish moisture resistance | 8 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm thick MDF core | |
|---|---|---|
| Tabletop surface veneer | 0.6mm natural oak wood veneer | |
| Tabletop edge finish | Rounded bullnose edge, veneer wrapped | |
| Tabletop coating | Matte UV cured polyurethane finish | |
| Pedestal base structure | Engineered wood composite core with oak veneer wrap | |
| Base bottom protection | 5mm thick felt floor glides | |
| Hardware connection | M8 steel mounting bolts with threaded inserts | |
| Substrate moisture content | 10% | |
| Veneer joint construction | Book-matched veneer splice, urea-formaldehyde adhesive | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating access | 360 degree unobstructed leg clearance around pedestal | |
|---|---|---|
| Floor protection | Pre-installed felt glides on base bottom | |
| Assembly requirement | 2-point tabletop to base connection | |
| Surface maintenance | Matte non-reflective finish hides minor scratches and fingerprints | |
| Stability design | Wider bottom pedestal footprint prevents tipping | |
| Seating configuration | Accommodates 4 standard dining chairs without leg interference | |
| Surface compatibility | Heat resistant finish supports 85°C tableware without surface damage | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of packages | 2 | |
|---|---|---|
| Tabletop carton dimensions | 1280 x 1280 x 90 mm | |
| Pedestal carton dimensions | 650 x 650 x 780 mm | |
| Total gross shipping weight | 55 kg | |
| Total shipping volume (CBM) | 0.46 | |
| assembly time | 20 minutes | |
| 40ft HQ container loading quantity | 132 units | |
| Total shipping volume | 0.46 CBM | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining rooms | 4-seater size fits small to medium apartment dining spaces, central pedestal allows flexible seating arrangement | |
|---|---|---|
| Small cafe and bistro seating | Durable wood finish and stable pedestal base suitable for light commercial food service use | |
| Open plan kitchen dinettes | 1200mm diameter does not overwhelm kitchen island adjacent spaces, rounded edges reduce injury risk in high traffic areas | |
| Home office meeting spaces | Serves as a small conference table for 4 person casual meetings, wood finish complements modern office interiors | |
| Showroom and model home staging | Minimalist tapered pedestal design works for contemporary and mid-century modern interior styling | |
| Temporary event seating | Lightweight pedestal design is easy to reposition for pop-up events and small private function seating |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety - Requirements for domestic dining tables, applicable for static load and stability testing | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for the assessment of surface resistance to cold liquids, applicable for tabletop spill resistance | |
| EN 15187:2006 | Furniture - Assessment of surface resistance to dry heat, applicable for verifying tabletop heat resistance to hot tableware |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional tolerance, material quality and structural stability of this dining table | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, required formaldehyde emission limit ≤1.5mg/L for acceptance inspection | |
| GB/T 4893.4-2013 | Test method for surface film adhesion of wooden furniture coatings, applicable for verifying finish adhesion durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional tolerance, material quality and structural stability of this dining table; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, required formaldehyde emission limit ≤1.5mg/L for acceptance inspection; 3. GB/T 4893.4-2013: Test method for surface film adhesion of wooden furniture coatings, applicable for verifying finish adhesion durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
