Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 22 kg | |
|---|---|---|
| Static tabletop uniform load capacity | 50 kg | |
| Seating capacity | 2 persons | |
| Base anti-tip lateral load resistance | 15 kg | |
| Tabletop surface scratch resistance | 3000 cycles | |
| Recommended warranty period | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 18mm thick MDF substrate | |
|---|---|---|
| Tabletop surface | 0.6mm light oak wood veneer with matte clear lacquer | |
| Tabletop edge banding | Matching solid oak edge trim | |
| Pedestal column | 1.5mm thick seamless steel tube with white powder coat | |
| Base plate | 2mm thick stamped steel disc with white powder coat | |
| Internal connection hardware | M10 steel mounting bolt with lock washer | |
| Floor protection pad | 3mm thick non-slip EVA pad on base bottom | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Single pedestal support | Center column provides unobstructed legroom for all seated positions | |
|---|---|---|
| Floor protection design | EVA pads under base prevent scratches on hard flooring and improve grip | |
| Fixed height configuration | 750mm standard dining height compatible with standard dining chairs | |
| Round tabletop layout | 800mm diameter allows flexible seating placement without corner obstruction | |
| Leveling adjustment | Optional hidden floor glides compensate for 5mm floor unevenness | |
| Easy assembly design | Tabletop attaches to pedestal with 4 bolts for 20-minute tool-assisted assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small apartment dining area | Compact 800mm diameter fits studio and 2person household dining spaces | |
|---|---|---|
| Casual meeting nook | Small round top supports 2-person casual discussion in office break areas | |
| Cafe bistro seating | Classic tulip style suits modern casual dining venues with paired armless dining chairs | |
| Balcony leisure area | Compact weather-resistant coated base works for covered outdoor balcony refreshment use | |
| Open plan lounge side table | 750mm height functions as an occasional table for drinks and decor in lounge zones |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic furniture safety | EN 12521:2015 Furniture – Strength, durability and safety for domestic tables | |
|---|---|---|
| Formaldehyde emission | EN 13986:2004+A1:2015 Wood-based panels for construction – Formaldehyde Class E1 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Table stability test | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Surface film performance | GB/T 4893.4Furniture surface wear resistance test | |
| Base metal coating adhesion | GB/T 9286Cross cut test for coating adhesion |
This product must meet the following technical requirements: 1. Table stability test: GB/T 3324General technical requirements for wooden furniture; 2. Surface film performance: GB/T 4893.4Furniture surface wear resistance test; 3. Base metal coating adhesion: GB/T 9286Cross cut test for coating adhesion; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
