| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1070 x 1070 x 740 mm | |
|---|---|---|
| Tabletop diameter | 1070 mm | |
| Tabletop thickness | 25 mm | |
| Pedestal floor base diameter | 610 mm | |
| Stem diameter at narrowest point | 80 mm | |
| Floor to tabletop underside clearance | 734 mm | |
| Stem top flare diameter (at tabletop connection) | 250 mm | |
| Stem bottom flare diameter (at floor plate) | 380 mm | |
| Floor contact pad thickness | 3 mm | |
| Edge radius (tabletop perimeter) | 3 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 120 kg | |
|---|---|---|
| Assembled product net weight | 70 kg | |
| Standard seating capacity | 4 people | |
| Finish abrasion resistance rating | 40000 cycles | |
| Base anti-tip static stability load | 30 kg lateral force at top edge | |
| Maximum recommended tabletop point load | 35 kg | |
| Limited warranty period | 1 year | |
| Available color finish count | 1 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | High-density MDF core with smooth matte white lacquer finish | |
|---|---|---|
| Tabletop edge banding | Matching matte white PVC edge banding sealed to perimeter | |
| Pedestal stem construction | 1.5mm thick cold-rolled steel, welded to top and bottom flanges | |
| Floor base plate | 2mm thick weighted cold-rolled steel circular plate, powder coated matte white | |
| Surface finish coating | Chip-resistant matte white powder coat/lacquer, uniform across base and top | |
| Floor protection pads | 4 non-slip soft EVA pads affixed to base bottom, 3mm thick | |
| Assembly hardware | Zinc-plated steel M8 mounting bolts with lock washers, predrilled pilot holes | |
| Connection reinforcement plate | 3mm thick steel mounting plate between stem and tabletop core | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Assembly method | Knock-down assembly connecting tabletop, stem, and base with included hex key | |
|---|---|---|
| Leg room access | 360-degree unobstructed leg clearance around single central pedestal | |
| Floor protection | Soft non-slip pads under base prevent hard floor scratches and dampen movement | |
| Surface cleaning | Non-porous smooth finish wipes clean with damp cloth, resists common household stains | |
| Seating arrangement | Accommodates 4 standard dining chairs evenly around table perimeter | |
| Weight distribution | Wide circular floor base disperses table and load weight evenly across floor contact area | |
| Fixed height design | Static 740mm dining height optimized for standard 450mm seat height dining chairs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping volume (CBM) | 0.24 CBM | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining space | Small to medium dining nooks seating 4, modern minimalist interior design schemes | |
|---|---|---|
| Kitchen breakfast area | Open-plan kitchen dining use, easy to clean surface for daily meal service | |
| Cafe/bistro seating | Small casual dining establishments for 4 guests, durable metal base for high traffic | |
| Home office meeting nook | Small informal meeting space for 4people in contemporary home offices | |
| Apartment/condo furnishing | Compact footprint suits urban small-space living without blocking walkways |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for pedestal table stability under lateral load |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop and structure | |
|---|---|---|
| GB/T 4893.1-2021 | Surface paint film abrasion and stain resistance testing for finished furniture | |
| GB/T 10357.1-2013 | Mechanical test method for table furniture strength and stability | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop and structure; 2. GB/T 4893.1-2021: Surface paint film abrasion and stain resistance testing for finished furniture; 3. GB/T 10357.1-2013: Mechanical test method for table furniture strength and stability; 4. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
