Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 1200 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table net weight | 48 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 136 kg | |
| Recommended seating capacity | 4 people | |
| Surface horizontal stability tolerance | 2 mm | |
| Finish abrasion resistance | 400 cycles | |
| Structural warranty period | 2 years | |
| Tipping load threshold at table edge | 28 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm thick MDF core with oak veneer | |
|---|---|---|
| Tabletop veneer layer | 0.6mm natural sliced oak veneer with open grain finish | |
| Tabletop finish coat | Matte polyurethane clear coat, 0.15mm dry film thickness | |
| Pedestal base substrate | Wood composite core with matching oak veneer wrap | |
| Base floor contact pad | 5mm thick non-marking felt pad, full perimeter of base | |
| Tabletop-to-base connection hardware | 8mm steel threaded inserts with 60mm hex bolts | |
| Edge banding | Matching solid oak edge lipping, 2mm thickness | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed height dining surface | 750mm work height compatible with standard 450mm seat height dining chairs | |
|---|---|---|
| Center pedestal leg design | No perimeter leg obstruction allows flexible chair placement around entire table edge | |
| Leveling adjustment | Integrated micro-adjust glides at base perimeter compensate for 10mm floor unevenness | |
| Non-porous sealed finish | Resists common household food and beverage spills with dry cloth cleaning | |
| Knock-down assembly design | Two-part construction (top + base) enables flat-pack shipping and in-home assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room use | Fits compact 4-seat dining spaces in apartments and small homes, mid-century aesthetic | |
|---|---|---|
| Open-plan kitchen dining nook | Pedestal design eliminates leg obstructions for casual family meal seating | |
| Small office break room | Provides seating for 4 staff in compact break areas, durable surface for food and drink use | |
| Cafe and bistro seating | Stable construction supports high-traffic commercial food service use with appropriate chair pairing | |
| Recommended pairing | Match with four armless 450mm seat height dining chairs, optional 600mm lazy Susan for shared dining |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, structural performance test standard | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface finishes of wooden furniture, abrasion and stain resistance evaluation |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural performance and finish quality | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, formaldehyde emission limit |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural performance and finish quality; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, formaldehyde emission limit; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
