Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 900 x 750 mm | |
|---|---|---|
| Tabletop diameter | 900 mm | |
| Tabletop thickness | 38 mm | |
| Central pedestal column diameter | 60 mm | |
| 4-star base foot spread diameter | 660 mm | |
| Seating knee clearance height | 690 mm | |
| Base foot length from center hub | 330 mm | |
| Table edge radius | 19 mm | |
| Floor clearance under base hub | 22 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Recommended seating capacity | 4 people | |
|---|---|---|
| Maximum static distributed tabletop load | 120 kg | |
| Product net weight | 26 kg | |
| Surface scratch resistance rating | Grade 2 per furniture abrasion testing | |
| Leveling adjustment range per foot | 10 mm | |
| Surface water resistance | Sealed to prevent liquid penetration into core material | |
| Recommended warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | Medium-density fiberboard (MDF) engineered wood | |
|---|---|---|
| Tabletop surface finish | White matte scratch-resistant lacquer coating | |
| Central pedestal column | Chrome-plated steel tube with polished finish | |
| 4-star base arms | Chrome-plated steel with polished finish | |
| Base hub connection | Die-cast steel connector between column and base arms | |
| Foot end pads | Non-slip black rubber non-marking pads | |
| Fastener hardware | Zinc-plated steel bolts and washers | |
| Coating thickness on metal parts | 0.08 mm chrome plating layer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Table structure | Fixed rigid pedestal assembly with no moving parts | |
|---|---|---|
| Floor leveling | Screw-adjustable rubber pads on each base foot to correct uneven floors | |
| Chair accommodation | Central support leaves full table perimeter unobstructed for chair placement | |
| Surface maintenance | Smooth non-porous finish wipes clean with damp cloth for food and drink spills | |
| Assembly requirement | Knockdown construction requiring attachment of base column and feet to tabletop | |
| Floor protection | Rubber foot pads prevent scratches to hard tile, wood and vinyl flooring | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small apartment dining area | Compact 900mm diameter fits studio or eat-in kitchen spaces without obstruction | |
|---|---|---|
| Cafe or bistro seating | Polished metal base and easy-clean top suit casual food service environments | |
| Home office break room | Small footprint provides seating for employee snacks or casual meetings | |
| Balcony casual dining | Weather-resistant sealed top and rust-resistant chrome base suit covered outdoor use | |
| Reception lounge side seating | Clean minimalist style complements modern office or waiting area décor | |
| Recommended companion seating | 4 standard armless dining chairs with 450mm seat height |
EU Market Access Requirements* EN Standards
| Furniture surface scratch resistance | EN 15186:2012 | |
|---|---|---|
| Dining table stability test | EN 1730:2012 | |
| Metal furniture finish durability | EN 12720:2013 |
US and Canada office-furniture standards
| Table static load test | ANSI/BIFMA X2021Clause 5 |
|---|
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 18580E1 grade | |
|---|---|---|
| Dining table structural stability | GB/T 3324General technical requirements for wooden furniture | |
| Metal surface coating adhesion | GB/T 9286Cross-cut test grade 1 | |
| Furniture mechanical safety | GB 28007Stability and strength requirements for children/adult furniture |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 18580E1 grade; 2. Dining table structural stability: GB/T 3324General technical requirements for wooden furniture; 3. Metal surface coating adhesion: GB/T 9286Cross-cut test grade 1; 4. Furniture mechanical safety: GB 28007Stability and strength requirements for children/adult furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
