Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1100 × 1100 × 750 mm | |
|---|---|---|
| Tabletop diameter | 1100 mm | |
| Tabletop thickness | 35 mm | |
| Pedestal base top diameter (at tabletop junction) | 380 mm | |
| Pedestal base bottom diameter (floor contact) | 450 mm | |
| Knee clearance height (under tabletop) | 690 mm | |
| Knee clearance radius from central pedestal | 335 mm | |
| Tabletop edge overhang beyond pedestal | 360 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 45 kg | |
|---|---|---|
| Maximum distributed static tabletop load | 100 kg | |
| Recommended seating capacity | 4 people | |
| Anti-tip stability (offset edge load) | 30 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Impact resistance (tabletop edge) | 10 J | |
| Net product weight | 45 kg | |
| Maximum offset edge static load (anti-tip) | 35 kg | |
| Recommended formal seating capacity | 4 people | |
| Surface abrasion resistance rating | 2000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 18mm MDF substrate | |
|---|---|---|
| Tabletop finish | High-gloss white PU lacquer | |
| Tabletop edge | Bullnose polished lacquer edge | |
| Pedestal base construction | Conical flared rigid base, high-gloss white lacquer finish | |
| Base floor contact pad | Non-marking felt/rubber glide | |
| Tabletop to base connection | Steel mounting plate with M8 mounting bolts | |
| Internal base weighting | Cast iron or concrete weight core | |
| Tabletop core substrate | 35mm thick medium-density fiberboard (MDF) E1 grade | |
| Tabletop surface finish | High-gloss white UV-cured PU lacquer, 0.2mm total coating thickness | |
| Tabletop edge treatment | Bullnose rounded polished lacquer edge, no separate edge banding | |
| Pedestal outer shell | Molded conical MDF or FRP shell with matching high-gloss white PU lacquer | |
| Pedestal internal weight core | Cast iron stabilizing weight core |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating access | Unobstructed 360-degree access around entire table perimeter | |
|---|---|---|
| Surface cleaning | Smooth non-porous glossy surface compatible with standard office disinfectants | |
| Assembly requirement | Two-part assembly requiring attachment of tabletop to pedestal base via included hardware | |
| Floor protection | Non-marking glides prevent scuffing and scratching to hard flooring and carpet | |
| Leveling adjustment | Fixed height, non-adjustable base | |
| Use versatility | Compatible with standard height (450 mm seat height) office task and guest chairs | |
| Surface maintenance | Sealed non-porous lacquer surface compatible with pH-neutral commercial disinfectants and cleaners | |
| Assembly requirements | Two-part knock-down assembly, tabletop attached to pre-assembled pedestal base via included M8 bolts | |
| Stability performance | Lowered center of gravity from internal cast iron core prevents tipping during normal use and table repositioning | |
| Chair compatibility | Compatible with standard 450mm seat height dining, meeting and guest chairs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping packages | 1 unit per 2 cartons | |
|---|---|---|
| Tabletop carton dimensions | 1160 x 1160 x 90 mm | |
| Pedestal carton dimensions | 520 x 520 x 720 mm | |
| Total shipping gross weight | 55 kg | |
| Total shipping volume (CBM) | 0.36 cbm | |
| Required assembly time | 20 minutes | |
| 20ft GP container loading quantity | 72 units | |
| 40ft HQ container loading quantity | 185 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small office meeting rooms | 1100mm diameter seats 4 people, suitable for 4person team discussions or video calls | |
|---|---|---|
| Office breakout and lounge areas | Glossy minimalist finish complements modern office design, suitable for casual employee breaks or informal conversations | |
| Reception waiting areas | Compact footprint works in reception spaces, suitable for holding visitor reading materials, drinks and decorative items | |
| Small cafe and co-working spaces | Flexible size works for individual work or small group meetings, durable lacquered surface withstands high-traffic commercial use | |
| Private office side meeting table | Fits adjacent to executive desks for small in-office meetings, non-obtrusive pedestal design avoids visual clutter | |
| Small office meeting and huddle rooms | 1100mm diameter seats 4 people for team discussions, video calls and quick meetings; compact footprint fits 12sqm huddle room spaces | |
| Modern office breakout and lounge areas | Glossy minimalist white finish matches contemporary office design; pedestal base eliminates trip hazards for high-traffic employee lounge use | |
| Reception and visitor waiting areas | Compact footprint fits in reception zones, suitable for holding reading materials, visitor drinks and decorative items; easy-to-clean surface maintains a polished professional appearance |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 15372:2016 Furniture - Strength, durability and safety for non-domestic tables | Applies to structural performance requirements for commercial office meeting tables | |
|---|---|---|
| EN 12521:2015 Furniture - Strength, durability and safety for domestic tables | Applicable if product is specified for hospitality or breakout area use | |
| EN 71-3:2019 Safety of toys - Migration of certain elements | Relevant if table is specified for early education or childcare spaces, sets limits for harmful substance migration from surfaces | |
| EN 717-1:2004 Wood-based panels - Determination of formaldehyde release | Applicable standards and test results require confirmation |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 Desk Products - Tests | Applies to static load, cyclic load, stability and durability testing for commercial office tables |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to dimensional tolerance, surface finish quality and structural stability requirements for lacquered wooden commercial tables | |
|---|---|---|
| GB/T 4893.1-2005 Test for surface resistance to cold liquids | Recommended acceptance requirement for tabletop lacquer finish to resist damage from common office beverages and cleaning products | |
| GB/T 10357.1-2013 Furniture mechanical performance test for tables | Applies to static load, impact and stability testing for general office tables | |
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Recommended acceptance requirement for formaldehyde and heavy metal emissions from lacquer and MDF substrates | |
| GB/T 4893.8-2013 Test for surface abrasion resistance of furniture coatings | Applicable to lacquer wear resistance testing to validate 2000-cycle abrasion performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to dimensional tolerance, surface finish quality and structural stability requirements for lacquered wooden commercial tables; 2. GB/T 4893.1-2005 Test for surface resistance to cold liquids: Recommended acceptance requirement for tabletop lacquer finish to resist damage from common office beverages and cleaning products; 3. GB/T 10357.1-2013 Furniture mechanical performance test for tables: Applies to static load, impact and stability testing for general office tables; 4. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Recommended acceptance requirement for formaldehyde and heavy metal emissions from lacquer and MDF substrates; 5. GB/T 4893.8-2013 Test for surface abrasion resistance of furniture coatings: Applicable to lacquer wear resistance testing to validate 2000-cycle abrasion performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
