Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 700 × 700 × 720 mm | |
|---|---|---|
| Tabletop diameter | 700 mm | |
| Tabletop thickness | 25 mm | |
| Base diameter | 450 mm | |
| Pedestal shaft minimum diameter | 70 mm | |
| Undertable knee clearance height | 685 mm | |
| Edge radius | 3 mm | |
| Floor contact footprint diameter | 450 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 17 kg | |
|---|---|---|
| Static tabletop load capacity | 50 kg | |
| Recommended seated user count | 2 | |
| Base anti-tip stability load | 15 kg | |
| Surface scratch resistance rating | 2H | |
| Recommended service life | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 25mm thick medium density fiberboard (MDF) | |
|---|---|---|
| Tabletop finish | Matte white polyurethane paint, 0.15mm dry film thickness | |
| Central pedestal stem | 1.5mm thick cold-rolled steel, tapered trumpet shape | |
| Floor base plate | 2.0mm thick cold-rolled steel, circular disc | |
| Base and stem finish | Matte white powder coating, 0.08mm coating thickness | |
| Tabletop to pedestal connection | M8 steel threaded insert with 60mm diameter metal mounting plate | |
| Floor protection | 3mm thick non-slip EVA foam pads installed under base perimeter | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Obstruction-free seating | Central single pedestal design eliminates corner legs, allows unobstructed chair placement around full table perimeter | |
|---|---|---|
| Fixed height design | Non-adjustable 720mm working height, matched to standard dining chair and side chair seat heights | |
| Easy surface cleaning | Smooth non-porous painted finish allows wipe cleaning with standard household cleaners, no seams or grout lines | |
| Freestanding installation | No wall mounting required, stable free standing placement on any level hard floor surface | |
| Leveling adjustment | Hidden micro-adjustable feet at base underside compensate for up to 5mm floor unevenness to eliminate wobble | |
| Indoor use suitability | Finish rated for dry indoor environments only, not for permanent outdoor exposure | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 750 x 750 x 770 mm | |
| Gross shipping weight | 19 kg | |
| Shipment volume per unit | 0.433 CBM | |
| 20ft GP container loading quantity | 60 units | |
| 40ft HQ container loading quantity | 150 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Used as a side table next to sofas or armchairs for drinks, books, and decorative items | |
|---|---|---|
| Casual dining nook | Serves as a small bistro table for kitchen corners or studio apartments for two-person dining | |
| Office breakout area | Suitable for informal meeting spaces, waiting areas, or cafe corners in workplace environments | |
| Cafe and lounge seating | Used in small coffee shops, co-working spaces, or hotel lobbies for lightweight patron seating | |
| Balcony indoor use | Placed in enclosed sunrooms or covered balconies for casual drinks and leisure | |
| Showroom display | Used for product display in retail environments or exhibition booths |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
