Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1000 × 1000 × 760 mm | |
|---|---|---|
| tabletop diameter | 1000 mm | |
| tabletop thickness | 30 mm | |
| leg section size (top attachment) | 60 x 40 mm | |
| leg section size (floor contact) | 30 x 30 mm | |
| cross-stretcher width | 45 mm | |
| floor to cross-stretcher clearance | 220 mm | |
| under-table knee clearance height | 670 mm | |
| leg spread diameter at floor | 920 mm | |
| overhang from leg attachment to table edge | 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| net product weight | 25 kg | |
|---|---|---|
| static distributed tabletop load capacity | 100 kg | |
| recommended seating capacity | 4 people | |
| leg connection shear load per joint | 120 kg | |
| finish abrasion resistance | 4000 cycles | |
| wood moisture content at delivery | 10% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop surface layer | 0.6mm thick light oak wood veneer | |
|---|---|---|
| tabletop core substrate | 18mm thick MDF or particleboard core | |
| table edge banding | Matching solid wood edge banding | |
| table legs | Solid rubberwood tapered splayed legs | |
| cross-stretcher bracing | Solid rubberwood interlocking X-frame | |
| surface finish | Matte clear nitrocellulose lacquer | |
| foot pads | 5mm thick non-slip PE plastic floor glides | |
| assembly hardware | Zinc-plated steel hex bolts and barrel nuts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| tabletop configuration | Fixed non-extendable circular top | |
|---|---|---|
| structural support | Four-point splayed leg with X-cross stretcher | |
| assembly requirement | Knockdown leg and brace attachment to top | |
| floor protection | Replaceable plastic glides on each leg foot | |
| leveling adjustment | Fixed non-adjustable leg height | |
| surface use suitability | Heat resistant up to 80C for short contact | |
| cleaning compatibility | Wipe-clean with damp cloth and mild detergent | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| small apartment dining nook | 1000mm diameter fits compact kitchen and studio spaces without blocking circulation | |
|---|---|---|
| casual kitchen dining area | Light natural oak finish complements neutral Scandinavian or mid-century interiors | |
| small café seating area | Durable solid wood construction supports daily commercial light use | |
| home office meeting corner | Can function as a small informal meeting table for 3people | |
| balcony enclosed sunroom dining | Sealed wood finish resists minor humidity fluctuations in semi-sheltered spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for table surfaces |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to domestic dining tables | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to domestic dining tables; 2. GB 18584-2001: Limit of harmful substances in wood furniture for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
