Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 813 x 813 x 762 mm | |
|---|---|---|
| Tabletop diameter | 813 mm | |
| Tabletop thickness | 23 mm | |
| Floor base diameter | 600 mm | |
| Under-table knee clearance height | 700 mm | |
| Pedestal column minimum diameter | 76 mm | |
| Pedestal column connection diameter at base | 200 mm | |
| Edge profile radius | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net product weight | 15.9 kg | |
|---|---|---|
| Maximum static distributed tabletop load | 120 kg | |
| Seating capacity | 4 diners | |
| Powder coat finish scratch resistance | Grade 2 per standard furniture testing | |
| Laminate surface heat resistance | 80 °C | |
| Table stability lateral load capacity | 30 kg applied at top edge | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | Medium-density fiberboard (MDF) | |
|---|---|---|
| Tabletop surface | Grey laminate finish with subtle stone/cement pattern | |
| Tabletop edge trim | Matching grey PVC edge banding | |
| Central pedestal column | 1.5mm thick steel tubing with matte black powder coat | |
| Floor base disc | 2mm thick stamped steel with matte black powder coat | |
| Mounting hardware | Zinc-plated steel bolts and connecting plates | |
| Surface finish coating thickness (base) | 60 microns | |
| Floor protective pads | 10mm thick non-slip EVA pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Knock-down assembly structure | 3 main components (top, pedestal, base) for flat-pack shipping | |
|---|---|---|
| 360-degree unobstructed seating access | Central pedestal eliminates corner leg obstructions | |
| Fixed non-tilting tabletop | Rigid bolted connection between top and pedestal | |
| Uneven floor level adjustment | 4 integrated threaded foot pads under base | |
| Surface cleaning compatibility | Wipe-clean laminate surface resistant to common food spills | |
| Fixed height design | 762mm standard dining height | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small apartment dining nooks | Compact 800mm diameter footprint fits limited floor space without crowding | |
|---|---|---|
| Open-plan kitchen breakfast areas | Slim pedestal design complements modern minimalist kitchen interiors | |
| Small home office meeting spaces | Provides compact surface for 4person casual discussions or laptop work | |
| Cafe and bistro seating areas | Durable metal base and wipe-clean top suit light commercial food service use | |
| Studio apartment multi-use spaces | Doubles as dining table, work surface, or serving table for small gatherings | |
| Contemporary rental property furnishing | Neutral grey/black finish matches a wide range of decor schemes for turnkey fitouts |
EU Market Access Requirements* EN Standards
| EN 12521:2015 Furniture - Strength, durability and safety for domestic dining tables | Relevant standard for structural safety and load performance verification | |
|---|---|---|
| EN 13722:2004 Furniture - Test methods for surface finishes - Resistance to cold liquids | Applicable to laminate surface spill resistance verification |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to tabletop substrate, dimensional tolerance and surface durability requirements | |
|---|---|---|
| GB/T 4893.8-2013 Furniture surface test: Wear resistance | Applicable to laminate tabletop abrasion performance acceptance | |
| GB/T 10357.1-2013 Furniture mechanical test: Tables - Strength and durability | Applicable to static load and stability testing for domestic dining use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to tabletop substrate, dimensional tolerance and surface durability requirements; 2. GB/T 4893.8-2013 Furniture surface test: Wear resistance: Applicable to laminate tabletop abrasion performance acceptance; 3. GB/T 10357.1-2013 Furniture mechanical test: Tables - Strength and durability: Applicable to static load and stability testing for domestic dining use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
