Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 750 mm | |
|---|---|---|
| Tabletop diameter | 800 mm | |
| Tabletop thickness | 25 mm | |
| Pedestal column top diameter | 120 mm | |
| Pedestal column bottom diameter | 80 mm | |
| Square base side length | 450 mm | |
| Square base thickness | 12 mm | |
| Under-table knee clearance height | 705 mm | |
| Clearance between base edge and table edge | 175 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 18 kg | |
|---|---|---|
| Tabletop static load capacity | 91 kg | |
| Recommended seating capacity | 2 people | |
| Surface scratch resistance | 2000 cycles | |
| Base anti-slip floor contact | 4 pads | |
| Wobble deflection under full load | 2 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 18mm thick MDF engineered wood | |
|---|---|---|
| Tabletop finish | Matte light blue PU paint | |
| Tabletop edge banding | 1mm thick PVC edge trim | |
| Pedestal column | 1.5mm thick powder-coated steel | |
| Square base plate | 12mm thick powder-coated cast iron | |
| Floor protection pads | Rubber non-slip pads | |
| Connection hardware | Zinc-plated steel screws | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly requirement | Knock-down screw-together assembly | |
|---|---|---|
| Surface function | Waterproof stain-resistant tabletop | |
| Leg space design | 360-degree unobstructed knee clearance | |
| Stability performance | Weighted square base anti-tip design | |
| Placement flexibility | Freestanding no-floor-mount design | |
| Cleaning requirement | Wipe-clean smooth surface | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Café and bistro seating | Suitable for 2-person casual dining and drink service in commercial food spaces | |
|---|---|---|
| Office breakout and reception areas | Ideal for holding refreshments during informal meetings or waiting periods | |
| Balcony and small home leisure spaces | Compact footprint fits tight residential outdoor or indoor lounge areas | |
| Retail store consultation corners | Provides a flat surface for product samples and customer discussion | |
| Event pop-up temporary seating | Lightweight knock-down design supports rapid deployment for temporary events |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic furniture mechanical safety standard | EN 12521:2015 | |
|---|---|---|
| Furniture surface emission standard | EN 13986:2004+A1:2015 | |
| Furniture hardware fastener standard | EN 14073:2004 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop furniture physical dimension standard | GB/T 3324 | |
|---|---|---|
| Furniture surface paint film performance standard | GB/T 4893.1 | |
| Metal furniture coating performance standard | GB/T 3325 |
This product must meet the following technical requirements: 1. Tabletop furniture physical dimension standard: GB/T 3324; 2. Furniture surface paint film performance standard: GB/T 4893.1; 3. Metal furniture coating performance standard: GB/T 3325; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
