Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 900 × 750 mm | |
|---|---|---|
| tabletop thickness | 25 mm | |
| central pedestal column diameter | 76 mm | |
| 4-star base leg length (center to foot end) | 440 mm | |
| base spread (maximum foot-to-foot diagonal) | 880 mm | |
| base foot glide height | 5 mm | |
| knee clearance height under tabletop | 720 mm | |
| knee clearance radius from central column | 375 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| net product weight | 18 kg | |
|---|---|---|
| static tabletop load capacity | 100 kg | |
| recommended seating capacity | 4 people | |
| base static stability load offset rating | 20 kg | |
| foot glide floor protection rating | 10000 abrasion cycles | |
| surface abrasion resistance | 300 cycles (Martindale) | |
| suggested warranty period | 3 years | |
| base static stability offset load rating | 20 kg | |
| foot glide floor abrasion resistance | 10000 cycles | |
| tabletop surface abrasion resistance | 300 Martindale cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop substrate | 25mm thick engineered quartz composite | |
|---|---|---|
| tabletop edge finish | Seamless rounded polished edge | |
| central support column | 1.2mm thick chrome-plated steel tube | |
| 4-star base legs | 1.5mm thick polished chrome-plated steel | |
| top mounting plate | 3mm thick powder-coated steel | |
| leg end glides | Injection molded hard PVC | |
| chrome plating thickness | 0.15 micron decorative chrome over nickel plating | |
| chrome plating layer | 0.15 micron decorative chrome over 8 micron nickel plating | |
| tabletop moisture content | 0.5% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| floor level adjustment | Threaded PVC glides provide 8 mm of height adjustment at each foot | |
|---|---|---|
| fixed height work surface | 750 mm fixed standing/sitting height | |
| non-protruding base design | 4-star base legs terminate 10 mm inside tabletop perimeter | |
| easy surface maintenance | Non-porous engineered stone surface resists liquid spills | |
| scratch-resistant top surface | Hard composite top withstands daily use from crockery, devices and stationery | |
| tool-free glide adjustment | Threaded foot glides adjust by hand without tools | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| number of shipping cartons | 1 unit | |
|---|---|---|
| shipping carton dimensions | 950 x 950 x 120 mm | |
| gross shipping weight | 22 kg | |
| shipping volume per unit | 0.11 CBM | |
| assembly time | 20 minutes | |
| 20ft GP container loading quantity | 240 units | |
| 40ft HQ container loading quantity | 600 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| small residential dining area | Fits compact kitchen or apartment dining nooks, seats 4people for daily meals with minimal footprint | |
|---|---|---|
| office break-out and meeting space | Suitable for small informal meetings, coffee breaks or touchdown work areas in corporate offices | |
| cafe and bistro seating | Pairs with armless dining chairs for boutique cafe, hotel lobby or lounge food service areas | |
| reception and waiting areas | Used as a side table for holding magazines, drinks or decorative items in waiting rooms, salons or clinics | |
| recommended chair pairing | Matches chairs with 460 mm seat height, no armrests or narrow armrests to tuck fully under the table edge | |
| compact residential dining area | Fits small apartment or studio kitchen dining nooks, seats 4 adults for daily meals with minimal floor space occupancy | |
| office break-out space | Suitable for small informal meetings, coffee breaks or touchdown laptop work areas in corporate office environments | |
| medical and salon waiting areas | Used as a side table for holding magazines, water cups or decorative arrangements in clinic waiting rooms or hair salons |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 15372:2008 Furniture - Strength, durability and safety - Requirements for domestic tables | Covers structural load, stability and edge safety requirements for residential dining table use | |
|---|---|---|
| EN 13722:2004 Furniture - Strength, durability and safety - Requirements for non-domestic tables | Applicable if product is specified for cafe, office break-out or light contract environments |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to tabletop substrate dimensional stability, edge finishing and structural strength requirements for indoor use | |
|---|---|---|
| GB/T 24821-2009 Office tables | Relevant for dimensional tolerances, stability and load testing if used as small office meeting table | |
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Sets formaldehyde emission limits for any wood-based components in the table assembly |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to tabletop substrate dimensional stability, edge finishing and structural strength requirements for indoor use; 2. GB/T 24821-2009 Office tables: Relevant for dimensional tolerances, stability and load testing if used as small office meeting table; 3. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Sets formaldehyde emission limits for any wood-based components in the table assembly; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
