Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Tabletop overhang from column | 540 mm | |
| Central support column diameter | 120 mm | |
| Central support column height | 670 mm | |
| Star base leg spread diameter | 780 mm | |
| Base leg floor contact point length | 390 mm | |
| Floor clearance under tabletop edge | 720 mm | |
| Knee clearance zone diameter around column | 960 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 38 kg | |
|---|---|---|
| Static distributed tabletop load capacity | 100 kg | |
| Recommended maximum seated users | 4 people | |
| Base static stability load | 150 kg | |
| Surface impact resistance | 1.5 J | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 3 years | |
| Maximum recommended seated users | 4 people | |
| Base tip resistance load | 150 kg | |
| Edge bond strength | 1.2 N/mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 25mm thick medium-density fiberboard (MDF) | |
|---|---|---|
| Tabletop finish | High-gloss white UV cured lacquer | |
| Edge banding | 2mm thick matching white PVC edge banding | |
| Central support column | 1.5mm thick cold rolled steel tube | |
| Star base legs | 2mm thick cold rolled steel prongs | |
| Base connection hub | Cast steel welded hub | |
| Floor contact pads | 8mm thick non-marking rubber glides | |
| Mounting hardware | Grade 8.8 zinc plated steel bolts | |
| Tabletop mounting plate | 3mm thick powder-coated steel plate | |
| Chrome finish corrosion resistance | 48 hours | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Height configuration | Fixed 750mm working height | |
|---|---|---|
| Seating access | 4 equal unobstructed access points | |
| Surface function | Smooth non-porous high-gloss surface | |
| Floor protection | Non-marking rubber glides on all base feet | |
| Assembly design | Flat-pack knockdown construction | |
| Stability performance | Centered pedestal design provides equal weight distribution | |
| Color option availability | 2 standard finishes | |
| Surface performance | Non-porous smooth high-gloss surface | |
| Glide adjustment | 5mm vertical adjustment per floor glide | |
| Color availability | 2 standard finish options | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Shipping carton dimensions | 1250 x 1250 x 150 mm | |
| Gross shipping weight | 43 kg | |
| Shipping volume per unit | 0.23 CBM | |
| Required assembly time | 30 minutes | |
| 20ft GP container loading quantity | 110 units | |
| 40ft HQ container loading quantity | 270 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
| Small meeting rooms | Fits 4 meeting attendees, compact footprint works for 4person discussion areas in open plan offices, with full knee clearance for all seats | |
|---|---|---|
| Cafe and breakroom dining | Wipe-clean high-gloss surface supports food and beverage use, chrome base resists scuffs and is easy to sanitize for high-traffic employee break areas | |
| Small residential dining areas | Space-efficient round design fits compact apartment dining nooks, minimalist aesthetic matches modern contemporary interior styles | |
| Temporary event and exhibition seating | Lightweight single-pillar design is easy to reposition, 4-person capacity works for catering stations, visitor registration and small event breakout zones | |
| Reception and lounge waiting areas | Provides polished surface for displaying literature, beverages or decor in office reception zones, base design avoids trip hazards in high foot traffic areas | |
| Small office meeting rooms | 4-person capacity fits compact discussion zones in open-plan offices, full knee clearance supports 60-minute meetings without discomfort; recommended due to 1200mm footprint and stable pedestal design | |
| Commercial cafe and breakroom dining | Wipe-clean high-gloss surface supports frequent food and beverage use, chrome base resists scuffs and sanitizer damage in high-traffic employee break areas; selected for commercial-grade durability | |
| Small residential dining nooks | Space-efficient round design fits 2.4m x 2.4m apartment dining areas, minimalist white/chrome finish matches modern and Scandinavian interior styles; suitable due to compact scale and neutral aesthetic |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture - Strength, durability and safety for non-domestic tables, sets performance requirements for commercial use in offices, cafes and meeting spaces | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applies for residential and light commercial dining applications | |
| EN 1022:2018 | Furniture - Seating - Determination of stability, referenced as stability baseline for pedestal table design to prevent tipping during use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to tabletop substrate strength, edge bonding quality and dimensional tolerance checks for procurement acceptance | |
|---|---|---|
| GB/T 4893.1-2021 | Furniture surface test for liquid resistance, required to verify the high-gloss finish resists common coffee, water and cleaning product stains during acceptance | |
| GB/T 4893.8-2013 | Furniture surface abrasion resistance test, sets minimum acceptance criteria for tabletop finish durability in commercial use | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, mandatory formaldehyde emission limit for MDF substrates | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, specifies static load and stability testing methods for acceptance; recommended standard, verify via test report |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to tabletop substrate strength, edge bonding quality and dimensional tolerance checks for procurement acceptance; 2. GB/T 4893.1-2021: Furniture surface test for liquid resistance, required to verify the high-gloss finish resists common coffee, water and cleaning product stains during acceptance; 3. GB/T 4893.8-2013: Furniture surface abrasion resistance test, sets minimum acceptance criteria for tabletop finish durability in commercial use; 4. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, mandatory formaldehyde emission limit for MDF substrates; 5. GB/T 10357.1-2013: Furniture mechanical performance test for tables, specifies static load and stability testing methods for acceptance; recommended standard, verify via test report; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
