Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 770 mm | |
|---|---|---|
| Tabletop diameter | 800 mm | |
| Tabletop thickness | 25 mm | |
| Floor base diameter | 450 mm | |
| Pedestal narrowest point diameter | 60 mm | |
| Pedestal top connection diameter | 150 mm | |
| Under-table leg clearance height | 720 mm | |
| Table edge radius | 3 mm | |
| Seating perimeter clearance | 2513 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 13 kg | |
|---|---|---|
| Static vertical tabletop load capacity | 120 kg | |
| Recommended seating capacity | 4 people | |
| Surface water resistance rating | Level 2 | |
| Base stability tilt resistance | 15 degrees | |
| Finish abrasion resistance | 2000 cycles | |
| Formaldehyde emission grade | P2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 25mm P2 grade engineered wood MDF | |
|---|---|---|
| Tabletop surface finish | High-gloss white baked varnish | |
| Central pedestal | 1.2mm thick cold-rolled steel tube | |
| Pedestal and base finish | Matched white powder coating | |
| Floor base plate | 2mm thick stamped steel circular plate | |
| Floor protection pads | 5mm thick non-slip EVA gaskets | |
| Mounting hardware | Zinc-plated steel M8 connector bolts | |
| Top-to-pedestal connection plate | 3mm thick pre-drilled steel mounting plate | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly structure | Knock-down construction with 3 core components | |
|---|---|---|
| Seating access | 360-degree unobstructed perimeter seating | |
| Surface maintenance | Stain-resistant wipe-clean surface | |
| Floor protection | Non-marking EVA pads under base | |
| Stability design | Wide weighted circular floor base | |
| Installation requirement | Single-person assembly with included hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small apartment dining nook | Fits compact 4person eating areas with minimal floor space occupation | |
|---|---|---|
| Kitchen breakfast area | Works as casual dining surface adjacent to kitchen counter spaces | |
| Cafe and bistro seating | Suitable for commercial small-table food service seating arrangements | |
| Home office meeting space | Functions as small round conference table for 3person discussions | |
| Balcony casual seating | Suitable for covered outdoor balcony use with weather-resistant finish | |
| Rental property furnishing | Durable easy-clean design ideal for short-term and long-term rental units |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety strength durability requirements for domestic dining tables | |
|---|---|---|
| EN 312:2010 | Performance requirements for MDF wood panels used in furniture construction | |
| EN 13722:2004 | Test methods for furniture surface finish resistance to liquids and abrasion |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for tabletop and structural safety | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for MDF core material | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable for glossy top coating |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for tabletop and structural safety; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for MDF core material; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable for glossy top coating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
