Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 800 x 760 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Central support column diameter | 76 mm | |
| Round base diameter | 400 mm | |
| Base disc thickness | 8 mm | |
| Edge trim thickness | 2 mm | |
| Unobstructed knee clearance height | 705 mm | |
| 360-degree seating clearance radius | 400 mm | |
| Mounting bracket plate diameter | 150 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net product weight | 30 kg | |
|---|---|---|
| Distributed tabletop static load capacity | 100 kg | |
| Seating capacity | 4 people | |
| Base floor contact area | 125664 mm² | |
| Finish surface abrasion resistance | 2000 cycles | |
| Chrome base rust protection coating thickness | 8 μm | |
| Tabletop moisture resistance rating | Level 2 | |
| Recommended static floor load rating | 238 kg/m² | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm MDF engineered wood core | |
|---|---|---|
| Tabletop surface | Walnut-effect melamine laminate finish | |
| Tabletop edge | Black PVC edge banding | |
| Central support column | Chrome-plated 1.2mm wall thickness steel tube | |
| Base disc | 1.0mm wall thickness chrome-plated steel round plate | |
| Connection hardware | Zinc-plated steel M8 mounting bolts and bracket | |
| Floor protection | 3mm thick non-slip EVA foam pads affixed to base underside | |
| Column connection collar | Polished chrome cast steel joint at column-base interface | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment | Fixed 760mm standard dining height, no lift mechanism | |
|---|---|---|
| Seating access | 360-degree unobstructed access around central pedestal | |
| Surface use | Smooth non-porous laminate surface supports dining, laptop, and beverage use | |
| Assembly requirement | Knock-down assembly with three core components (top, column, base) | |
| Floor stability | Wide round disc base distributes weight to prevent tipping on level floors | |
| Cleaning compatibility | Water-resistant surface allows wipe-down cleaning with standard household cleaners | |
| Movement capability | Lightweight construction allows repositioning by two people without disassembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small dining nooks | Fits compact apartment dining areas to seat 4people for daily meals | |
|---|---|---|
| Commercial cafe seating | Suitable for coffee shop and bistro indoor seating areas with durable surface | |
| Office break rooms | Works as informal break area seating for staff eating and casual collaboration | |
| Balcony casual seating | Appropriate for covered outdoor balcony use with rust-resistant chrome base | |
| Reception waiting areas | Provides small table surface for magazines and beverages in waiting zones | |
| Student dormitory common areas | Serves as shared small study and dining surface in residence hall spaces |
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Furniture – Strength, durability and safety for non-domestic tables, applicable for commercial cafe use | |
|---|---|---|
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables, applicable for home use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, optional reference for commercial contract grade compliance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for tabletop structural performance | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture, applicable for laminate top validation | |
| GB/T 10357.1-2013 | Table mechanical stability test standard, applicable for pedestal base load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for tabletop structural performance; 2. GB/T 4893.8-2013: Surface wear resistance test method for furniture, applicable for laminate top validation; 3. GB/T 10357.1-2013: Table mechanical stability test standard, applicable for pedestal base load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
