Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | Φ800 x 760 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Central pedestal column diameter | 76 mm | |
| 4-prong cross base spread | 610 mm | |
| Single cross foot length | 300 mm | |
| Cross foot cross-section width | 40 mm | |
| Under-table knee clearance height | 720 mm | |
| Tabletop edge lip thickness | 12 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 12 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 120 kg | |
| Recommended seating capacity | 4 people | |
| Base static stability load offset | 30 kg | |
| Powder coating thickness | 80 μm | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop construction | Diamond-lattice perforated steel mesh with rolled steel rim | |
|---|---|---|
| Central support column | Seam-welded powder-coated steel tube | |
| Cross base feet | Cast iron with matte black powder coating | |
| Foot pads | Injection-molded non-slip nylon floor protectors | |
| Surface finish system | E-coat primer with matte black powder topcoat | |
| Assembly hardware | Zinc-plated steel bolts and lock washers | |
| Tabletop support plate | 3mm thick steel mounting plate welded to column top | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Freestanding pedestal support | Single central column creates 360° unobstructed legroom around the table perimeter | |
|---|---|---|
| Floor leveling adjustment | Threaded adjustable feet on each cross base end | |
| Weather-resistant surface | Perforated mesh tabletop allows rainwater drainage for outdoor use | |
| Knock-down assembly | Tabletop, column and base ship disassembled for compact transport | |
| Umbrella compatibility | Optional central 60mm diameter hole fits standard patio umbrella poles | |
| Scratch-resistant surface | Cured powder coat resists scuffs from tableware, drinkware and daily use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Commercial cafe patio use | Compact footprint fits small outdoor seating areas for food service operations | |
|---|---|---|
| Residential balcony dining | 800mm diameter fits small balcony spaces for 4person casual meals | |
| Indoor breakfast nook placement | Unobstructed pedestal design works in compact kitchen dining corners | |
| Bistro bar sidewalk seating | Stable 4-prong base resists tipping on slightly uneven sidewalk surfaces | |
| Contract break room furnishing | Easy-to-clean metal surface supports daily breakroom use for staff dining |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Safety requirements for outdoor seating and tables for domestic and contract use | |
|---|---|---|
| EN 581-3:2017 | Mechanical safety and performance test methods for outdoor tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to structural safety and finish performance | |
|---|---|---|
| GB/T 17657-2013 | Test methods for surface finish durability, abrasion and corrosion resistance for metal furniture surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to structural safety and finish performance; 2. GB/T 17657-2013: Test methods for surface finish durability, abrasion and corrosion resistance for metal furniture surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
