Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 900 x 500 mm | |
|---|---|---|
| Top surface diameter | 900 mm | |
| Lower storage shelf diameter | 840 mm | |
| Tabletop thickness | 15 mm | |
| Vertical support slat cross-section | 20 x 30 mm | |
| Vertical support slat count | 16 units | |
| Floor clearance under lower shelf | 20 mm | |
| Lower shelf to top surface vertical clearance | 420 mm | |
| Top edge banding thickness | 2 mm | |
| Lower shelf usable surface depth from edge | 400 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total static load capacity (tabletop) | 136 kg | |
|---|---|---|
| Product net weight | 22 kg | |
| Veneer wear resistance rating | 2000 abrasion cycles | |
| Recommended maximum number of place settings/decor items | 6 units | |
| Surface water repellency rating | Class B | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 15mm P2 grade MDF | |
|---|---|---|
| Tabletop finish | Walnut wood grain PVC veneer with matte lacquer topcoat | |
| Lower shelf substrate | 12mm P2 grade MDF | |
| Vertical support slats | Solid rubberwood with dark walnut stain | |
| Circular perimeter frame rails | Laminated engineered wood with matching veneer wrap | |
| Hardware connectors | Zinc-plated steel confirmat screws and cam locks | |
| Bottom frame contact points | Non-slip EVA foam pads | |
| Finish coating thickness | 0.15mm matte UV lacquer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Two-tier open storage layout | Upper circular surface for beverage/ decor placement, lower open shelf for book/basket storage | |
|---|---|---|
| Stationary floor-standing design | Fixed non-adjustable height, no moving parts or extending mechanisms | |
| Evenly spaced slat frame | 16 vertical slats create open visual airflow between tiers while supporting structural load | |
| Pre-drilled assembly holes | All components include pre-drilled alignment points for tool-enabled flat-pack assembly | |
| Smooth rounded tabletop edge | Radius 10mm rounded edge profile eliminates sharp corners for household safety | |
| Floor protection function | EVA pads on bottom frame prevent scratches to tile, wood and laminate flooring | |
| Easy surface maintenance | Wipeable non-porous finish allows spill cleanup with dry or lightly dampened cloth | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room center placement | Positioned in front of sofas for beverage, decor and remote control storage | |
|---|---|---|
| Small apartment living spaces | 900mm diameter fits compact seating layouts without blocking walkways | |
| Home office lounge areas | Placed in reception seating zones for guest beverage and reading material placement | |
| Neutral dark walnut styling | Coordinates with mid-century modern, minimalist and traditional wood furniture schemes | |
| Open shelf display use | Lower shelf suitable for displaying books, decorative trays or potted plants |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic living room tables | |
|---|---|---|
| EN 312:2010 | Particleboard performance requirements for structural furniture use | |
| EN 71-3:2019 | Migration of certain elements, applicable if used in households with children |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test method for furniture finishes, minimum 2000 cycles required |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for acceptance; 3. GB/T 4893.8-2013: Surface abrasion resistance test method for furniture finishes, minimum 2000 cycles required; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
