Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 600 x 600 x 750 mm | |
|---|---|---|
| Table top diameter | 600 mm | |
| Table base disc diameter | 450 mm | |
| Table pedestal stem diameter | 80 mm | |
| Overall chair dimensions | 620 x 580 x 780 mm | |
| Chair seat height from floor | 450 mm | |
| Chair seat width | 520 mm | |
| Chair seat depth | 480 mm | |
| Chair integrated backrest height | 330 mm | |
| Chair base disc diameter | 420 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single chair net weight | 18 kg | |
|---|---|---|
| Chair static load capacity | 150 kg | |
| Seating capacity per set (1 table + 2 chairs) | 2 adults | |
| Seat cushion compression set resistance | 40% | |
| Surface scratch resistance rating | 3H | |
| Cushion foam rebound rate | 40% | |
| Upholstery seam tensile strength | 80 N | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Chair outer shell | Gloss white gel-coated fiberglass-reinforced plastic (FRP) | |
|---|---|---|
| Chair seat and back cushion core | 40mm thick high-resilience polyurethane foam, 35kg/m³ density | |
| Chair cushion upholstery | Stain-resistant PU leather, 0.8mm thickness, 50000 cycle Martindale abrasion resistance | |
| Table top | Gloss white gel-coated FRP, 10mm nominal thickness | |
| Table and chair pedestal stems | Powder-coated cast aluminum, 5mm wall thickness | |
| Table and chair base discs | Cast iron with white powder-coated finish, weighted for anti-tip stability | |
| Base floor glides | Non-marking polyethylene felt pads | |
| Upholstery attachment | Stapled concealed fastening under shell lip | |
| Chair swivel bearing | Sealed carbon steel ball bearing, 12mm inner diameter | |
| Finish coating | UV-cured gloss polyester gel coat, 0.3mm dry film thickness | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Wrap-around back support | Curved integrated side/back structure provides lateral and lumbar support for relaxed short-duration seating of up to 2 hours per session | |
|---|---|---|
| Swivel function for chairs | 360 degree smooth rotation via sealed bearing between stem and base, no tilt or height adjustment | |
| Tables have fixed height working surface | 750mm fixed top height, designed to align with 450mm seat height for comfortable arm rest when seated | |
| Stable anti-tip design | Wide weighted circular floor base distributes weight to prevent tipping when users lean or pull chairs away from table | |
| Non-marking floor protection | Soft glides on base bottoms prevent scratches and scuffs on polished marble, tile or terrazzo flooring | |
| Easy-clean smooth surfaces | Gloss non-porous FRP surfaces and wipeable PU upholstery allow sanitization with standard commercial cleaning products | |
| Chair swivel rotation | 360 degree smooth rotation via sealed bearing between stem and base, no tilt or height adjustment, rotation resistance torque of 2 N·m for controlled movement | |
| Fixed table working surface | 750mm fixed top height, designed to align with 450mm seat height for 250mm vertical leg clearance between table underside and floor | |
| Anti-tip stability | Wide weighted circular floor base distributes weight to achieve 12 degree tilt angle without tipping when users lean or pull chairs away from table | |
| Sanitizable easy-clean surfaces | Gloss non-porous FRP surfaces and wipeable PU upholstery allow sanitization with 75% alcohol or neutral commercial cleaning products without finish damage | |
| Uniform modular alignment | All chairs and tables share matched pedestal dimensions and finish, allowing flexible reconfiguration into 2, 4 or 6 seat clusters without visual mismatch | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Number of packages per 1-table + 2-chair set | 3 packages | |
|---|---|---|
| Table carton dimensions | 680 x 680 x 780 mm | |
| Single chair carton dimensions | 670 x 630 x 810 mm | |
| Gross weight per full 1+2 set | 70 kg | |
| Total CBM per full set | 0.91 m³ | |
| Assembly time per set | 20 minutes | |
| 20ft GP container loading quantity (full sets) | 30 sets | |
| 40ft HQ container loading quantity (full sets) | 72 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate lobby and waiting areas | Cohesive white and green aesthetic complements polished stone flooring and modern interior finishes, suitable for short-duration visitor seating | |
|---|---|---|
| Bank and service hall public waiting zones | Easy-clean surfaces and durable construction withstand high daily visitor traffic, stable bases prevent trip hazards in high-footfall spaces | |
| Exhibition and event lounge spaces | Lightweight swivel chairs and matching tables create flexible modular seating clusters that can be reconfigured for different event layouts | |
| Hospital and clinic patient waiting areas | Smooth non-porous surfaces support regular disinfection, comfortable seat height accommodates a wide range of adult users | |
| Shopping mall rest zones | Gloss scratch-resistant finish maintains appearance after constant public use, compact footprint maximizes seating capacity in narrow corridor rest areas | |
| Office breakout and casual meeting zones | 360 degree swivel function supports casual 2-person conversation, table size accommodates laptop use for 30 minute informal work sessions | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 15372:2016 Furniture - Seating for non-domestic use - Safety requirements | Applicable safety standard for commercial non-domestic lounge seating, covering strength, stability and durability | |
|---|---|---|
| EN 12521:2015 Furniture - Tables for non-domestic use - Safety requirements | Applicable strength, stability and surface durability standard for commercial side/occasional tables | |
| EN 13722:2004 Furniture - Test methods for the assessment of surface resistance to cold liquids | Applicable for verifying surface stain and cleaning chemical resistance for public space furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for furniture | Applicable for dimensional stability, edge finishing and structural safety requirements for domestic and commercial wooden and plastic furniture | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde and heavy metal emission limits for any composite structural components | |
| GB/T 10357.2-2013 Test of mechanical properties of furniture - Stability of seating | Applicable for anti-tip stability testing of the lounge chairs to ensure safety for public use | |
| GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of seating | Applicable for seat and back static load, fatigue testing for commercial seating installations |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for furniture: Applicable for dimensional stability, edge finishing and structural safety requirements for domestic and commercial wooden and plastic furniture; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde and heavy metal emission limits for any composite structural components; 3. GB/T 10357.2-2013 Test of mechanical properties of furniture - Stability of seating: Applicable for anti-tip stability testing of the lounge chairs to ensure safety for public use; 4. GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of seating: Applicable for seat and back static load, fatigue testing for commercial seating installations; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
