Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 750 mm | |
|---|---|---|
| Tabletop diameter | 800 mm | |
| Tabletop total thickness | 24 mm | |
| Brushed steel column outer diameter | 60 mm | |
| Black lower column outer diameter | 60 mm | |
| Black disc base diameter | 600 mm | |
| Disc base plate thickness | 8 mm | |
| Under-table knee clearance height | 726 mm | |
| Knee clearance radius | 370 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 26 kg | |
|---|---|---|
| Static tabletop vertical load capacity | 80 kg | |
| Recommended seating capacity | 3 persons | |
| Base anti-tip stability rating | Passes 15-degree tilt test without overturning | |
| Surface scratch resistance | 3000 abrasion cycles | |
| Steel column connection load rating | 120 kg | |
| Recommended warranty period | 2 years | |
| Available color variants | 3 options | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop decorative surface | 12 mm calacatta-style white faux marble with grey veining | |
|---|---|---|
| Tabletop structural substrate | 12 mm high-density fiberboard composite backing | |
| Tabletop edge trim | Thin matching PVC sealed edge | |
| Upper support column | Brushed 304 stainless steel tubing | |
| Lower support column | Matte black powder-coated steel tubing | |
| Floor contact base plate | 8 mm thick matte black powder-coated steel disc | |
| Mounting hardware | Zinc-plated steel bolts and floor glides | |
| Tabletop underside mounting plate | 3 mm thick galvanized steel bracket | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Leveling adjustment | Integrated 10 mm adjustable glides on base underside | |
|---|---|---|
| Fixed height design | 750 mm standard cafe/bistro working height | |
| Unobstructed leg space | Central pedestal eliminates corner leg obstructions | |
| Fixed non-folding structure | Permanent bolted connection between components | |
| Surface maintenance | Non-porous sealed tabletop finish | |
| Floor protection | Non-marking plastic glide pads on base | |
| Assembly requirement | Knockdown assembly of 3 core components (top, column, base) | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Commercial cafe and coffee shop seating | Compact 3person footprint for customer beverage and light meal service | |
|---|---|---|
| Office reception and waiting areas | Modern aesthetic for guest waiting spaces or small informal meeting zones | |
| Hotel lounge and breakout areas | Two-tone finish matches contemporary hospitality interior design schemes | |
| Residential balcony and small dining nooks | Compact circular design fits small urban apartment or balcony spaces | |
| Co-working space casual meeting spots | Unobstructed pedestal design supports flexible chair arrangement for quick meetings | |
| Restaurant outdoor covered patio use | Steel construction and sealed top withstand mild outdoor covered environments |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture - Strength, durability and safety for non-domestic seating area tables | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
| EN 13722:2004 | Furniture - Test methods for stability of tables |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to tabletop vertical load and stability testing | |
|---|---|---|
| ANSI/BIFMA X7.1-2020 | Formaldehyde emission standard for composite wood tabletop components |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to composite tabletop substrate | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/fiberboard requirements for furniture structural use, applicable to backing panel | |
| GB/T 1730-2007 | Hardness test standard for painted/coated metal surfaces on column and base | |
| GB 28007-2011 | Stability and safety requirements for household and commercial tables, applicable to anti-tip performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to composite tabletop substrate; 2. GB/T 4897.3-2015: Particleboard/fiberboard requirements for furniture structural use, applicable to backing panel; 3. GB/T 1730-2007: Hardness test standard for painted/coated metal surfaces on column and base; 4. GB 28007-2011: Stability and safety requirements for household and commercial tables, applicable to anti-tip performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
