Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 1800 x 600 x 1100 mm | |
|---|---|---|
| Main work surface height | 950 mm | |
| Raised rear riser height | 150 mm | |
| Raised rear riser dimensions | 1200 x 300 x 150 mm | |
| Desktop panel thickness | 25 mm | |
| Front body panel thickness | 18 mm | |
| PVC edge banding thickness | 2 mm | |
| Curved front corner radius | 50 mm | |
| LED recessed groove width | 20 mm | |
| Inner storage compartment depth | 550 mm | |
| Cable grommet diameter | 60 mm | |
| Ribbed front panel height | 350 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Unit net weight | 78 kg | |
| Storage shelf static load | 30 kg | |
| LED strip operational lifespan | 30000 hours | |
| Recommended user capacity | 2 staff | |
| Surface scratch resistance rating | 2000 cycles | |
| Moisture content of wood panels | 10% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop and rear riser | Light oak grain melamine-faced chipboard (MFC) | |
|---|---|---|
| Front cabinet body | Matte white melamine MDF panel | |
| Illuminated front section | Ribbed/textured white MDF panel | |
| Edge trim | 2mm thick PVC edge banding | |
| Accent lighting | Recessed warm white linear LED strip | |
| Structural framing | 1.2mm thick steel internal support brackets |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Accent lighting operation | Recessed LED strip casts soft ambient light along front V-groove | |
|---|---|---|
| Cable management | 60mm desktop grommet routes power/data cables to interior compartment | |
| Storage configuration | Dual lockable inner cabinet compartments with adjustable shelves | |
| Transaction surface use | Offset rear raised riser supports visitor check-in and document handover |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small office reception area | Provides visitor greeting and staff transaction space for 2front-of-house staff | |
|---|---|---|
| Retail cashier counter | Functions as checkout station with integrated storage for boutique/salon use |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Specification for particleboard for furniture structural use | |
|---|---|---|
| EN 14749:2016 | Safety requirements for domestic and commercial storage furniture | |
| EN 62471:2008 | Photobiological safety for integrated LED lighting products |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products, applicable for commercial reception units | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Performance standard for storage components integrated into workstations |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade recommended for indoor use | |
| GB/T 4897.3-2003 | Specification for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade recommended for indoor use; 3. GB/T 4897.3-2003: Specification for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
