Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint (L x W x H) | 2400 x 2200 x 1070 mm | |
|---|---|---|
| Staff work surface height | 750 mm | |
| Visitor-facing counter/riser height | 1070 mm | |
| Work surface depth (staff side) | 700 mm | |
| Work surface depth (visitor greeting side) | 600 mm | |
| Dual knee opening width (each side of pedestal) | 900 mm | |
| Knee clearance height under work surface | 680 mm | |
| Central storage pedestal width | 600 mm | |
| Raised privacy divider height above work surface | 320 mm | |
| Countertop thickness | 25 mm | |
| Edge band thickness on rounded bullnose ends | 2 mm | |
| Cable grommet diameter (desktop) | 80 mm | |
| Side panel thickness | 18 mm | |
| LED strip recess height at front corner end panel | 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total desktop static load capacity | 204 kg | |
|---|---|---|
| Seating capacity (reception staff) | 2 | |
| Desktop finish abrasion resistance | 2000 cycles | |
| Product net weight | 163 kg | |
| Corner LED strip operating lifespan | 50000 hours | |
| Anti-tip safety load rating | 91 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface and storage panels | 25mm E1 grade engineered wood with dark walnut grain thermally fused laminate | |
|---|---|---|
| Side and accent panels | 18mm engineered wood with matte dark gray powder-coat laminate finish | |
| Edge banding | 2mm PVC bullnose rounded edge trim on all exposed counter ends | |
| Drawer and cabinet hardware | Zinc alloy keyed-alike lock cylinders with steel drawer slides and hinges | |
| Cable management | ABS plastic recessed desk grommets with integrated cable pass-through slots | |
| Accent lighting | Low-voltage LED strip recessed into front corner end panel |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage functionality | Central lockable pedestal with 2 upper utility drawers and 2 lower cabinet doors for secure office supply storage | |
|---|---|---|
| Cable management | Two recessed desktop grommets route power, data and monitor cables below work surface to eliminate cord clutter | |
| Privacy screening | Segmented raised divider along visitor-facing edge blocks view of staff work surface while enabling transaction handoff | |
| Ambient lighting | Recessed LED strip at front corner provides soft low-level accent lighting for lobby atmosphere |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Commercial office lobby reception area | Designed for 2 front-desk staff to greet visitors, process check-ins and store supplies | |
|---|---|---|
| Retail or service front counter | Suitable for salon, clinic or customer service environments with modern two-tone aesthetic |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to commercial office use verification | |
|---|---|---|
| EN 13722:2004 | Furniture strength, durability and stability requirements for storage units, applicable to pedestal verification | |
| EN 14749:2016 | Domestic and kitchen storage units safety requirements, applicable to general casegoods safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to commercial office desk load and durability verification | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet durability verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural and finish quality verification | |
|---|---|---|
| GB/T 4897-2015 | Performance requirements for particleboard used in furniture construction, applicable to core panel verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to indoor air quality compliance | |
| GB/T 10357.1-1989 | Furniture mechanical performance test standard for tables, applicable to desk load and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural and finish quality verification; 2. GB/T 4897-2015: Performance requirements for particleboard used in furniture construction, applicable to core panel verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to indoor air quality compliance; 4. GB/T 10357.1-1989: Furniture mechanical performance test standard for tables, applicable to desk load and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
