Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2800 x 910 x 1140 mm | |
|---|---|---|
| Staff work surface height | 760 mm | |
| Visitor transaction counter height | 1140 mm | |
| Main front section width | 1800 mm | |
| Side return work surface depth | 600 mm | |
| Worktop thickness | 25 mm | |
| Front modesty panel height | 1000 mm | |
| Terracotta accent panel width | 1200 mm | |
| Plinth base height | 100 mm | |
| Under-worktop knee clearance height | 680 mm | |
| Side return section width | 1000 mm | |
| Edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Staff seating capacity | 2 positions | |
|---|---|---|
| Worktop static load capacity | 100 kg | |
| Total product net weight | 114 kg | |
| Drawer slide load rating | 25 kg | |
| Drawer/hinge cycle rating | 50000 cycles | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main panels | 15mm+ E1-grade engineered wood | |
|---|---|---|
| Work surfaces | 25mm melamine laminated particleboard | |
| Edge protection | 2mm thick PVC impact-resistant edge banding | |
| Front accent panel | 18mm laminated MDF terracotta finish | |
| Plinth base | 18mm laminated engineered wood light wood finish | |
| Hardware components | Powder-coated steel screws, cams and hardware |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Dual-height work design | Lower 760mm staff work surface, elevated 1140mm visitor transaction ledge | |
|---|---|---|
| Front privacy panel | Full-height solid modesty panel conceals staff legs from visitor view | |
| Cable management | Rear grommets and under-desk raceway route power/data cables | |
| Internal storage | Lockable drawer and adjustable cabinet shelf under return worktop |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office building lobbies | Suitable for corporate front-of-house greeting, sign-in and visitor transaction | |
|---|---|---|
| Retail and service boutiques | Works for salon, clinic, or small retail checkout and customer greeting |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable to office worktables strength, durability and stability | |
|---|---|---|
| EN 13722:2004 | Applicable to office reception furniture performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable to desk products performance and durability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Applicable to office furniture sustainability and material emissions |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to wooden office furniture general technical requirements | |
|---|---|---|
| GB 18580-2017 | Applicable to E1 grade formaldehyde emission limits for wood panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to wooden office furniture general technical requirements; 2. GB 18580-2017: Applicable to E1 grade formaldehyde emission limits for wood panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
