Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2215 x 701 x 1100 mm | |
|---|---|---|
| Staff work surface height | 750 mm | |
| Raised rear modesty riser height | 350 mm | |
| Raised rear modesty riser width | 800 mm | |
| Raised rear modesty riser depth | 200 mm | |
| Worktop thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Front facade height below worktop | 750 mm | |
| Staff side knee clearance height | 680 mm | |
| Staff side knee clearance depth | 600 mm | |
| Fluted front panel height | 300 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total worktop static load capacity | 181 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| LED accent light color temperature | 3000K | |
| Surface stain resistance rating | Level 3 | |
| Net product weight | 110 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Structural core panels | 25 mm thick MDF/engineered wood | |
|---|---|---|
| Cabinet front and side panels | Matte dark grey thermofused laminate | |
| Worktop and rear riser | Dark wood grain high-pressure laminate | |
| Front accent panel | Vertically fluted/grooved engineered wood laminate | |
| Accent lighting | Recessed LED strip lighting with diffused trim | |
| Worktop edge detail | 2 mm PVC bullnose edge banding |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Ambient lighting system | Integrated warm white LED strips along front V-accent and base | |
|---|---|---|
| Cable management | Rear-positioned cable grommets and under-desk cable tray | |
| Internal storage | Closed cabinet compartments with optional locking drawer and file storage | |
| Dual work zone | Lower staff work surface and raised rear privacy block |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Commercial office lobbies | Suitable for corporate reception areas, providing a professional first impression for visitors | |
|---|---|---|
| Retail and service front desks | Ideal for salons, clinics, boutiques, and co-working spaces with moderate visitor traffic |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance specification, applicable to structural panel load checks | |
|---|---|---|
| EN 13722:2004 | Furniture strength and durability for office reception counters | |
| EN 62471:2008 | Photobiological safety for integrated LED lighting components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to structural load and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural and finish quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to core panel materials | |
| GB/T 4897.3-2015 | Particleboard specification for furniture use, applicable to structural panel verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural and finish quality checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to core panel materials; 3. GB/T 4897.3-2015: Particleboard specification for furniture use, applicable to structural panel verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
