Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 3200 x 2400 x 1170 mm | |
|---|---|---|
| Rear return length | 1200 mm | |
| Working surface height | 750 mm | |
| Front public facade height | 1100 mm | |
| Countertop depth | 600 mm | |
| Total unit depth at widest point | 885 mm | |
| Under-counter knee clearance height | 680 mm | |
| Knee recess depth behind facade | 450 mm | |
| Countertop thickness | 25 mm | |
| Front faceted panel thickness | 18 mm | |
| Kick plate height from floor | 100 mm | |
| Cable grommet diameter | 80 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Countertop static load capacity | 150 kg | |
|---|---|---|
| Recommended staff seating capacity | 2 persons | |
| Net product weight | 280 kg | |
| Surface scratch resistance | 4 H | |
| Surface stain resistance rating | Grade 5 | |
| Optional drawer slide load rating | 25 kg per drawer | |
| Product warranty period | 10 years | |
| Hinge cycle rating for optional storage doors | 100000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Countertop | 12mm acrylic solid surface with seamless polished finish | |
|---|---|---|
| Front faceted facade | High-gloss UV-coated MDF panel with geometric diamond routing | |
| Internal structural frame | 18mm birch plywood with 1.5mm stainless steel support brackets | |
| Kick plate | 1.2mm powder-coated steel with scratch-resistant matte finish | |
| Cable management components | Brushed chrome grommets with nylon brush seals, PVC cable tray | |
| Optional internal drawer boxes | 15mm E0-grade melamine particleboard with soft-close slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable routing | Dual sealed grommets with under-counter cable tray for power/data access | |
|---|---|---|
| Work surface design | Continuous seamless countertop spanning both staff positions with raised privacy lip | |
| Knee access | Rear recessed open leg bay for unobstructed seated staff use | |
| Customization compatibility | Field-drillable for optional power outlets, LED accent lighting and locking drawers |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Applicable space | Corporate office lobbies, commercial building entrances and hotel reception areas | |
|---|---|---|
| Recommended configuration | Pair with ergonomic task chairs, queue management stanchions and visitor sign-in fixtures |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to work surface performance | |
|---|---|---|
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion, stains and heat for commercial tops | |
| EN 717-1:2004 | Wood-based panel formaldehyde emission determination, E1 class for indoor air quality |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and durability standard, applicable to static load and stability | |
|---|---|---|
| ANSI/BIFMA X7.1-2021 | Formaldehyde and TVOC emission limits for low-emitting office furniture | |
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for optional integrated drawer pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel and frame structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade required for indoor commercial use | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture structural use, load-bearing panel requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel and frame structural integrity; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade required for indoor commercial use; 3. GB/T 4897.3-2015: Particleboard specifications for furniture structural use, load-bearing panel requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
