Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 700 x 1070 mm | |
|---|---|---|
| Main transaction counter height | 750 mm | |
| Raised right privacy screen height | 1070 mm | |
| Countertop thickness | 50 mm | |
| Front LED accent strip length | 1800 mm | |
| Plinth base height | 50 mm | |
| Raised screen horizontal width | 1000 mm | |
| Front bevel panel angle | 15 degrees | |
| Internal storage cabinet depth | 620 mm | |
| Countertop overhang front | 20 mm | |
| Side panel thickness | 18 mm | |
| LED recess slot height | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 182 kg | |
|---|---|---|
| Countertop static load capacity | 150 kg | |
| Drawer slide load rating (per drawer) | 35 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge open/close cycle rating | 80000 cycles | |
| LED strip rated operational lifespan | 30000 hours | |
| Surface scratch resistance rating | 2H | |
| Recommended staff occupancy | 2 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet core substrate | 18mm E0 grade particleboard/MDF core | |
|---|---|---|
| Front facade panels | Dark smoked eucalyptus wood veneer over substrate with diamond bevel cut | |
| Countertop, raised screen and trim | Matte dark gray high-pressure laminate (HPL) with sealed edges | |
| Base plinth and trim strips | Matte dark gray powder-coated steel structural trim | |
| Accent lighting component | Recessed 3000K warm white LED strip with diffused lens in central facade slot | |
| Cabinet hardware | Soft-close drawer slides, adjustable hinges, cam-lock fasteners for assembly |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Ambient lighting function | Concealed front LED strip provides warm ambient lobby illumination for commercial aesthetics | |
|---|---|---|
| Storage functionality | Enclosed internal cabinet with adjustable shelves and lockable drawer for reception supplies | |
| Cable management function | Concealed rear routing channels and grommets for power/data cable organization | |
| Transaction surface function | Continuous flat countertop supports visitor check-in, document signing and decor placement |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packaging carton count | 3 cartons | |
|---|---|---|
| Largest carton dimensions | 2450 x 750 x 120 mm | |
| Total packaged gross weight | 205 kg | |
| Total shipment volume | 0.58 CBM | |
| On-site assembly time | 90 minutes | |
| 20ft GP container loading capacity | 24 units |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Applicable space | Corporate office lobbies, hotel front desks, and retail reception areas for professional front-of-house service | |
|---|---|---|
| User configuration | Designed for 2reception staff to manage visitor check-in, document processing and guest inquiries |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to reception work surfaces | |
|---|---|---|
| EN 15372:2016 | Office furniture storage units safety and durability requirements for cabinet components | |
| EN 62471:2008 | Photobiological safety for LED lighting products used in ambient accent strips |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial reception surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated cabinet and drawer components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet-based reception desk quality acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, mandatory requirement for indoor commercial furniture | |
| GB/T 4897-2015 | Performance requirements for particleboard substrates used in furniture cabinet construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet-based reception desk quality acceptance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, mandatory requirement for indoor commercial furniture; 3. GB/T 4897-2015: Performance requirements for particleboard substrates used in furniture cabinet construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
