Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2800 x 1825 x 1103 mm | |
|---|---|---|
| Raised visitor counter height | 1100 mm | |
| Staff working surface height | 750 mm | |
| Visitor counter overhang depth | 400 mm | |
| Staff work surface depth | 600 mm | |
| Return side depth (corner wrap) | 1225 mm | |
| Seated knee clearance height under work surface | 680 mm | |
| Desk panel thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Brown accent strip height below visitor counter | 150 mm | |
| Horizontal modesty panel groove position | Mid-height of front facade | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Top surface static load capacity | 120 kg | |
|---|---|---|
| Internal drawer dynamic load rating | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Product net weight | 136 kg | |
| Recommended maximum reception staff capacity | 2 | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main body panels | E1-grade engineered MFC with matte white melamine finish | |
|---|---|---|
| Left end side panel | Engineered wood with light beige wood-grain laminate finish | |
| Accent trim below visitor counter | Engineered wood with warm brown laminate finish | |
| Raised visitor countertop | 25mm thick engineered wood with light wood-grain high-pressure laminate | |
| Staff work surface | 25mm thick engineered wood with matte white high-pressure laminate | |
| Structural support frame | Powder-coated steel tube internal bracing |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | Dual cable grommets and under-desk cable tray to route power/data cords | |
|---|---|---|
| Front modesty panel | Full-height solid panel blocking seated staff leg area from public view | |
| Internal storage configuration | Lockable drawer, open storage shelf and keyboard tray under staff work surface | |
| Cantilevered visitor overhang | Extended raised counter projecting forward for guest check-in, paperwork and item placement |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Commercial office lobbies | Fits mid-size entry areas for corporate, co-working or professional service firms | |
|---|---|---|
| Salon and clinic reception areas | Provides check-in counter space and hidden staff workspace for customer-facing operations |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to staff work surface design | |
|---|---|---|
| EN 13722:2004 | Furniture strength, durability and stability for contract reception furniture use | |
| EN 14372:2004 | Surface resistance to abrasion, staining and heat for commercial laminate work surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard covering structural load, durability and stability for office use | |
|---|---|---|
| ANSI/BIFMA X7.1-2020 | Formaldehyde emission standard for low-emitting office furniture materials | |
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer and cabinet strength, cycle and load performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel reception desk structural performance | |
|---|---|---|
| GB/T 17657-2013 | Test methods for evaluating surface wear, stain resistance and bonding strength of wood panels | |
| GB 18580-2017 | Formaldehyde emission limit for E1-grade engineered wood panels, mandatory for indoor office furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel reception desk structural performance; 2. GB/T 17657-2013: Test methods for evaluating surface wear, stain resistance and bonding strength of wood panels; 3. GB 18580-2017: Formaldehyde emission limit for E1-grade engineered wood panels, mandatory for indoor office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
