Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2200 x 640 x 1100 mm | |
|---|---|---|
| Staff work surface height | 750 mm | |
| Raised visitor transaction counter height | 1100 mm | |
| Staff work surface depth | 585 mm | |
| Raised rear counter depth | 200 mm | |
| Inner staff knee clearance height | 720 mm | |
| Recessed base plinth height | 120 mm | |
| Left side storage pedestal width | 450 mm | |
| Tabletop and panel thickness | 38 mm | |
| Edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Kickspace recess depth | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 91 kg | |
|---|---|---|
| Work surface static load capacity | 100 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Recommended user capacity | 2 reception staff | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Core structural panels | 18mm thick E1 grade particleboard with low formaldehyde emission | |
|---|---|---|
| Work surfaces and raised counter | Dark walnut woodgrain thermally fused melamine laminate, scratch-resistant | |
| Front and side privacy panels | Matte charcoal grey melamine finish, fingerprint-resistant | |
| Base plinth | Ribbed/fluted MDF panel with diffused LED light channel | |
| Hardware components | Zinc-plated steel cam locks, screws, and connecting fittings with powder coated finish | |
| Edge protection | 2mm thick impact-resistant PVC edge banding matched to panel finishes |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Dual 80mm cable grommets with under-desk cable tray for power and data routing | |
|---|---|---|
| Integrated storage | Left-side enclosed pedestal with lockable file drawer and stationery drawer for office supplies | |
| Ambient plinth lighting | Recessed 3000K warm white LED strip along ribbed base for soft front illumination | |
| Staff work surface access | Full open rear access to seated work area with ergonomic knee clearance |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small to medium office lobby | Compact straight footprint fits entryways with 2.5m+ wall space for guest check-in | |
|---|---|---|
| Retail and service counters | Durable wipe-clean surfaces suit salon, clinic or boutique visitor transaction points |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to work surface load testing | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to drawer and cabinet durability | |
| EN 13722:2004 | Furniture test methods for surface abrasion resistance of laminate finishes |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability and stability testing of reception counters | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer slide, hinge and lock performance verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel compliance verification | |
| GB/T 4897.3-2015 | Performance requirements for particleboard used in furniture for structural load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel compliance verification; 3. GB/T 4897.3-2015: Performance requirements for particleboard used in furniture for structural load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
