Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2215 x 610 x 1092 mm | |
|---|---|---|
| Work surface height | 760 mm | |
| Work surface depth | 610 mm | |
| Privacy panel height above worktop | 332 mm | |
| Right storage pedestal width | 450 mm | |
| Central knee clearance width | 1765 mm | |
| Under-desk knee clearance height | 650 mm | |
| Worktop thickness | 25 mm | |
| PVC edge band thickness | 3 mm | |
| Cable grommet diameter | 80 mm | |
| Rear upper ledge depth | 100 mm | |
| Left end panel accent light recess height | 150 mm | |
| Base plinth height | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Work surface static load capacity | 113 kg | |
|---|---|---|
| Recommended seating capacity | 1 | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Net weight reference | 186 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm thick engineered wood substrate with dark walnut woodgrain melamine laminate, 3mm PVC edge banding | |
|---|---|---|
| Privacy panels and side panels | 18mm thick engineered wood with matte dark grey fingerprint-resistant laminate | |
| Drawer and cabinet fronts | 18mm thick engineered wood with matching dark walnut woodgrain laminate | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Lock mechanism | Zinc alloy keyed cam lock with 2 included keys | |
| Accent lighting | 12V warm white LED strip with recessed diffuser at left end panel base |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Right-side fixed pedestal with 1 locking top utility drawer and 1 lower hanging file cabinet for letter/legal files | |
|---|---|---|
| Cable management | Center work surface integrated cable grommet for routing power and data cables to under-desk space | |
| Privacy screening | Full-height continuous rear and end privacy panels that block view of behind-desk work area from visitor side | |
| Ambient lighting | Integrated warm white LED accent light at left end panel base for soft perimeter illumination |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Commercial office lobby reception | Provides staff work surface with visitor-side privacy screening and integrated storage for front-of-house greeting | |
|---|---|---|
| Retail or salon check-in counter | Durable scratch-resistant surface and lockable storage suit high-traffic customer check-in points |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office worktables safety and strength requirements, applicable to reception work surfaces | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to lockable drawer pedestal | |
| EN 12521:2015 | Furniture strength and durability for non-domestic seating-adjacent tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, strength and durability of commercial office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for performance of office drawer pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate case goods construction | |
|---|---|---|
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to melamine worktops |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate case goods construction; 2. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to melamine worktops; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
