Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2000 x 640 x 1100 mm | |
|---|---|---|
| Staff work surface height | 750 mm | |
| Customer-facing transaction ledge depth | 200 mm | |
| Staff knee clearance height | 720 mm | |
| Front kickplate/skirting height | 50 mm | |
| Worktop thickness | 25 mm | |
| Vertical support panel thickness | 18 mm | |
| Lower rear open shelf dimensions | 1800 x 150 x 300 mm | |
| Elevated accent display shelf dimensions | 1000 x 200 x 150 mm | |
| Edge banding thickness | 2 mm | |
| Modesty panel height | 700 mm | |
| Diagonal brace thickness | 18 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Overall product net weight | 100 kg | |
|---|---|---|
| Work surface static load capacity | 180 kg | |
| Recommended maximum seated staff count | 2 | |
| Surface scratch resistance rating | 4000 cycles | |
| Structural warranty period | 24 months | |
| Available finish color options | 3 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surfaces and trim | 25mm E1 grade engineered wood with bleached oak melamine veneer | |
|---|---|---|
| Front modesty and end panels | 18mm E1 grade engineered wood with matte white melamine finish | |
| Elevated accent shelf | 18mm engineered wood with light blue-grey matte paint finish | |
| Internal structural bracing | 18mm engineered wood diagonal support panel under central worktop | |
| Edge protection | 2mm thick PVC edge banding on all exposed panel edges | |
| Kickplate trim | 18mm bleached wood-grain engineered wood along bottom front edge |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Tiered rear display storage | Two lower open shelf compartments plus one elevated offset shelf for customer-facing materials | |
|---|---|---|
| Staff seating accommodation | Central open under-desk knee bay sized for standard office chair clearance | |
| Front privacy screening | Full-height solid modesty panel blocks under-workspace visibility from customer side | |
| Surface cleaning compatibility | Stain-resistant melamine finish supports wipe-down cleaning with standard office disinfectants |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small office lobbies | Ideal for 2reception staff in startup or small professional office entry spaces | |
|---|---|---|
| Retail boutique checkout | Suitable for small retail checkout with tiered shelves for product display at point of sale |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to staff work surface performance | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to integrated open shelf units | |
| EN 312:2010 | Performance specifications for particleboard used in dry-environment furniture construction |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for shelf load capacity and structural stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural integrity and finish performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade engineered wood components | |
| GB/T 4897.3-2015 | Performance requirements for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural integrity and finish performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade engineered wood components; 3. GB/T 4897.3-2015: Performance requirements for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
