Product supplierBlack High-Back Executive Swivel Chair with Polished Aluminum Base, Black leather-look surface, 1.2 mm target thickness, stitched over padded foam
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 660 × 700 × 1180 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 18 kg | |
|---|---|---|
| Recommended user weight capacity | 160 kg | |
| Seat foam density | 45 kg/m3 | |
| Back foam density | 35 kg/m3 | |
| Foam rebound | 40% | |
| Upholstery abrasion resistance | 50,000 cycles Martindale | |
| Gas-lift static load rating | 450 kg | |
| Base static load rating | 1136 kg | |
| Caster rolling durability | 100,000 cycles | |
| Seating capacity | 1 person |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat upholstery | Black leather-look surface, 1.2 mm target thickness, stitched over padded foam | |
|---|---|---|
| Backrest upholstery | Black upholstered outer and contact surfaces with segmented center panel and side bolsters | |
| Seat cushion | 90 mm high-resilience foam at 45 kg/m3 target density | |
| Back cushion | 70 mm padded foam at 35 kg/m3 target density with contoured lumbar form | |
| Inner seat frame | 18 mm plywood or 2.0 mm steel reinforced seat shell | |
| Back support frame | Steel tubular inner frame with 25 mm diameter and 1.8 mm wall target | |
| Arm pads | Black upholstered pads over 30 mm foam or soft polyurethane insert | |
| Arm supports | Polished aluminum-alloy or chrome-finished metal side supports with curved front edge | |
| Gas-lift column | Chrome-plated steel telescoping tube, 50 mm outer diameter | |
| Five-star base | Polished aluminum-alloy five-star base, 700 mm diameter, 3.0 mm wall target | |
| Casters | 60 mm black nylon twin-wheel casters with metal mounting stems | |
| Seam construction | Black thread with 8 stitches per 100 mm target seam pitch |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 360-degree swivel | Full 360-degree rotation around the central gas-lift bearing for multitask access | |
|---|---|---|
| Seat height adjustment | Pneumatic lift with 100 mm vertical stroke controlled by an under-seat lever | |
| Backrest recline | 15-degree backward tilt with tension control and one locked upright position | |
| Tilt tension control | Under-seat rotary knob adjusts backward resistance for users up to 160 kg | |
| Fixed arm support | Non-folding upholstered armrests provide 230 mm elbow support above the seat | |
| Mobile movement | Five 60 mm twin-wheel casters enable rolling on hard floors and low-pile carpet | |
| Lumbar posture support | Contoured center back panel and side bolsters provide passive lower-back alignment | |
| Rocking lock | Single-position tilt lock limits movement when the upright working position is selected | |
| Floor contact configuration | Five-point load distribution reduces tipping during normal reaching and swiveling | |
| Backrest recline angle | 15 degrees backward from upright | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Suited to manager and director offices where the high black back and polished base provide a formal appearance | |
|---|---|---|
| Private workstation | Supports 8-hour desk work with swivel, height change, recline, and caster mobility around a standard desk | |
| Meeting or boardroom use | Suitable for formal conference positions requiring upholstered comfort and a conservative black finish | |
| Home executive office | Appropriate for a dedicated home office with a desk depth of at least 700 mm | |
| Reception consultation area | Can be used behind a reception desk or in a premium consultation setting with hard-floor protection | |
| User size profile | Designed for a single adult with 160 kg target capacity and seat height up to 540 mm | |
| Floor compatibility | Use on wood, tile, laminate, or low-pile carpet; specify soft-wheel casters for scratch-sensitive hard floors | |
| Recommended Matching Desk Size | 2.4 m executive desk |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office chair safety and structural requirements | EN 1335:2018 Office furniture; office chair; safety requirements | |
|---|---|---|
| Office chair dimensional fit | EN 1335:2020 Office furniture; office chair; dimensions; determination of dimensions | |
| Office chair test methods | EN 1335:2020 Office furniture; office chair; safety test methods | |
| Upholstered furniture durability | EN 1728:2012 Domestic furniture; seating; test methods for strength and durability | |
| Office furniture fire assessment | EN 1021:2014 Ignition by smouldering cigarette and EN 1021:2014 match-flame equivalence |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Office chair safety and durability | ANSI/BIFMA X2017Office Chairs, Tests | |
|---|---|---|
| Sustainable furniture option | ANSI/BIFMA e2019Furniture Sustainability Standard | |
| Base and caster verification | ANSI/BIFMA X2017clauses for base test, caster durability, and stability |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Office chair safety applicability | GB/T 3324General technical requirements for wooden furniture, applicable only if wooden structural panels are used | |
|---|---|---|
| Upholstered furniture mechanical applicability | GB/T 33241Test methods for mechanical properties of upholstered furniture, applicable to seat and back durability testing | |
| Leather or artificial leather verification | GB/T 16799Furniture leather, applicable if the cover material is specified as leather | |
| Furniture indoor air evaluation | GB 28007Limits of harmful substances in upholstered furniture, applicable to odor, formaldehyde, and volatile substance checks |
Standardized tender description text
This product must meet the following technical requirements: 1. Office chair safety applicability: GB/T 3324General technical requirements for wooden furniture, applicable only if wooden structural panels are used; 2. Upholstered furniture mechanical applicability: GB/T 33241Test methods for mechanical properties of upholstered furniture, applicable to seat and back durability testing; 3. Leather or artificial leather verification: GB/T 16799Furniture leather, applicable if the cover material is specified as leather; 4. Furniture indoor air evaluation: GB 28007Limits of harmful substances in upholstered furniture, applicable to odor, formaldehyde, and volatile substance checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
