Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 640 x 620 x 1010 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended occupant weight | 160 kg | |
|---|---|---|
| Static seat load for procurement verification | 320 kg | |
| Backrest rearward pull test target | 136 kg | |
| Net weight | 13 kg | |
| Seat foam thickness | 80 mm | |
| Back foam thickness | 60 mm | |
| Seating capacity | 1 person | |
| Stacking or nesting capacity | 0 chairs | |
| Suggested cyclic durability test | 120,000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat contact upholstery | Light neutral synthetic leather or polyurethane-coated fabric over 80 mm foam | |
|---|---|---|
| Back contact upholstery | Light neutral smooth upholstery with segmented lumbar shaping | |
| Outer shell and arm panels | Dark charcoal upholstered panel wrapping around seat and back sides | |
| Piping and edge trim | Dark matching upholstered trim bonded around all panel edges | |
| Internal support shell | Molded plywood or engineered composite board with 12 mm target thickness | |
| Seat cushion foam | High-resilience polyurethane foam, 45 kg/m3 density and 80 mm thickness | |
| Back cushion foam | Polyurethane foam, 35 kg/m3 density and 60 mm thickness | |
| Cantilever frame | Chrome-plated welded steel tube, 25 mm diameter and 2.0 mm wall thickness | |
| Floor glides | Four injection-molded polymer glides attached at runner ends | |
| Joint construction | Steel support brackets connect the upholstered body to the cantilever frame | |
| Seam construction | Stitched and bonded upholstery seams with 8 stitches per 50 mm target | |
| Surface finish | Polished chrome metal finish with smooth dark and light upholstered faces |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed sitting posture | 450 mm seat height and 100-degree relaxed back angle provide fixed visitor seating | |
|---|---|---|
| Cantilever flex | Continuous steel sled base allows controlled seated flex without pivoting joints | |
| Integrated arm support | Wraparound upholstered side panels form fixed armrests at 220 mm above the seat | |
| Lumbar support | Shaped lower-back seam and padded back zone provide passive lumbar contour | |
| Floor protection | Four polymer end glides distribute load and reduce direct metal contact on floors | |
| Movement method | Non-swivel, non-caster chair intended to be repositioned by lifting or sliding | |
| Cleaning access | 300 mm under-seat clearance permits floor cleaning without moving the full chair far | |
| Noise reduction | Polymer glides isolate chrome tube ends from hard flooring during light movement | |
| Stacking restriction | Wide fixed arm panels and continuous runners prevent chair stacking | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive reception area | Use beside executive desks or reception seating groups for professional visitors | |
|---|---|---|
| Meeting room guest seating | Place around conference tables where fixed quiet seating is preferred | |
| Manager office visitor zone | Position in front of a desk for short-to-medium meetings | |
| Corporate lounge or breakout area | Use in pairs with a low table for refined employee or guest waiting areas | |
| Hotel or club business lounge | Suitable for premium lounges requiring polished metal and easy-to-maintain upholstery | |
| Boardroom anteroom | Deploy in waiting zones outside conference rooms where visual consistency matters | |
| Public service counters | Use at consultation or banking counters for short visitor sessions | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| Office furniture safety and strength | EN 16139 applies to non-domestic seating strength, durability and safety | |
|---|---|---|
| Upholstered furniture flammability | EN 1021covers cigarette ignition resistance of upholstery combinations | |
| Match ignition assessment | EN 1021covers match-flame ignition resistance of seat and back upholstery |
Standards applicable to China-market projects
| Furniture mechanical safety | GB/T 10357.2 applies to backrest strength and rearward stability verification | |
|---|---|---|
| Office chair dimensional guidance | GB/T 3326 applies to key dimensional measurement of seat, back and arm areas | |
| Furniture leather or artificial leather testing | GB/T 16799 applies when the selected cover material is synthetic leather | |
| Formaldehyde and interior material limits | GB 18580 applies to wood-based panels used inside the hidden support shell |
This product must meet the following technical requirements: 1. Furniture mechanical safety: GB/T 10357.2 applies to backrest strength and rearward stability verification; 2. Office chair dimensional guidance: GB/T 3326 applies to key dimensional measurement of seat, back and arm areas; 3. Furniture leather or artificial leather testing: GB/T 16799 applies when the selected cover material is synthetic leather; 4. Formaldehyde and interior material limits: GB 18580 applies to wood-based panels used inside the hidden support shell; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
