PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	620 × 650 × 1000 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended occupant load	130 kg
Net weight	16 kg
Seat foam density	45 kg/m3
Back foam density	35 kg/m3
Foam rebound rate	40%
Upholstery abrasion resistance	50000 Martindale cycles
Seat static-load verification	1020 N
Backrest static-load verification	410 N
Caster rolling durability	100000 cycles
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat upholstery	Burgundy upholstered surface with horizontal pleated channels
Back upholstery	Burgundy padded back with vertical gathered channels near upper and side zones
Seat cushion core	90 mm molded polyurethane foam over a load-bearing seat shell
Back cushion core	80 mm polyurethane padding attached to a shaped internal back panel
Internal seat support	12 mm plywood or equivalent molded composite seat board
Armrest structure	Curved fixed arms upholstered in the same burgundy material with internal rigid support
Tilt mechanism	Black powder-coated steel multi-position plate under the seat
Gas lift	Polished steel telescopic gas column with black actuator lever
Five-star base	Polished aluminum alloy five-star base with five radiating legs
Casters	Black nylon or polyurethane twin-wheel swivel casters, five total
Fasteners and brackets	Zinc-plated or blackened steel bolts, brackets, and arm mounting plates
Surface finish	Polished metal base with matte black mechanism and casters

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

360-degree swivel	Center gas column enables full 360-degree seat rotation for conversational and desk use
Height adjustment	Gas-lift lever provides an 100 mm seat-height travel around 460 mm
Back tilt	Synchro-style tilt plate permits recline with an 12-degree maximum back angle
Tilt lock	Multi-position lock is expected through the visible under-seat lever, including upright lock
Tilt tension adjustment	Rotary tension knob adjusts recline resistance for occupant weight up to 130 kg
Fixed arm support	Integrated curved fixed armrests provide 230 mm elbow support without height or width adjustment
Mobility	Five 60 mm twin-wheel casters provide rolling movement on hard floors and low-pile carpet
Five-point stability	Polished five-star base distributes occupant load and reduces tipping during swivel and tilt use
Channeled upholstery design	Vertical back channels and horizontal seat pleating retain padding and create the visible tailored pattern
Single-user task configuration	Designed for one adult occupant in meeting, executive, or computer-work posture
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Executive office	Suits a manager office where the burgundy tailored appearance pairs with wood or dark desking
Conference room	Suitable for meeting tables requiring swivel access and a uniform upholstered seating fleet
Consultation space	Appropriate for client meetings, advisory rooms, and reception discussions
Private workstation	Fits computer or writing work with an 460 mm seat height and 230 mm arm support
Hotel business center	Provides mobile seating in business lounges or guest workstations with formal visual styling
Low-pile carpet interiors	Twin-wheel casters are intended for hard floors and low-pile office carpet
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFC-MB-BUR-520

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFC-MB-BUR-520

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFC-MB-BUR-520Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mid-Back Padded Swivel Conference Chair, model OFC-MB-BUR-520, presents a tailored seating solution with a structured mid-back silhouette, coordinated burgundy upholstery, and a polished aluminum five-star base. Its seat uses horizontal pleated channels, while the padded back features vertical gathered detailing near the upper and side areas, creating a formal appearance suited to organized conference and office settings. Curved fixed armrests are upholstered in the same burgundy material and frame the seat without adjustment controls, supporting a clean, unified visual profile. Construction combines cushioned support with a durable under-seat structure. The seat contains a 90 mm molded polyurethane foam cushion over a load-bearing shell and a 12 mm plywood or equivalent molded composite support board. The back uses polyurethane padding attached to a shaped internal panel, with a defined lumbar support zone. Beneath the seat is a black powder-coated steel multi-position tilt mechanism, paired with a polished telescopic steel gas column and black actuator lever. The polished aluminum alloy base has five radiating legs and black twin-wheel casters, balancing a refined finish with practical mobility. Functionally, the chair supports full 360-degree swivel movement and gas-lift height adjustment with 100 mm of seat-height travel. A synchro-style tilt plate allows a 12-degree maximum back angle, while the under-seat lever provides multi-position locking including an upright setting. A rotary tension knob adjusts recline resistance for occupants up to 130 kg. The fixed arms offer continuous elbow support, and the casters are intended for hard floors and low-pile office carpet, making the chair easy to reposition around meeting tables or workstations. This model is well suited to conference rooms, manager or executive offices, private workstations, consultation and advisory spaces, reception discussion areas, hotel business centers, and business lounges. Its burgundy finish works particularly effectively with wood or dark desking and supports a consistent upholstered seating fleet across formal interiors. For procurement, buyers should note the chair is supplied unbranded as one set across two cartons, with packaged gross weight of 23 kg and a reference assembly time of 40 minutes per set. The upholstery is specified at 50,000 Martindale cycles, seat foam density at 45 kg/m3, back foam density at 35 kg/m3, and recommended occupant load at 130 kg. Projects should confirm flooring compatibility, assembly resources, storage volume, and delivery handling before bulk placement.

Mid-Back Padded Swivel Conference Chair Specifications
