PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	650 × 700 × 1220 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	150 kg
Net weight	19 kg
Seat foam density	45 kg/m3
Back foam density	35 kg/m3
Foam resilience	40%
Upholstery abrasion resistance	50,000 Martindale cycles
Base static load rating	500 kg
Caster rolling durability	100,000 cycles
Tilt mechanism durability	100,000 cycles
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat upholstery	Black smooth leather-look surface over padded cushion
Back upholstery	Black smooth upholstered two-zone back panel
Cushion core	Molded polyurethane foam, 90 mm target thickness
Back padding	Polyurethane foam sheet, 60 mm target thickness
Internal seat shell	12 mm molded plywood or reinforced polymer seat carrier
Back support frame	20 x 2.0 mm steel tubular inner frame
Armrest structure	Polished aluminum alloy continuous loop frame with tubular rail
Arm contact pad	Integrated 45 mm wide padded or leather-wrapped top rail
Gas lift	Chrome-plated steel telescopic gas cylinder, 50 mm diameter
Tilt mechanism	Black powder-coated steel plate synchro-tilt mechanism
Five-star base	Polished aluminum alloy five-star base with five radiating arms
Casters	Black nylon twin-wheel casters with hard tread, 60 mm diameter

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Swivel function	360-degree swivel around the central gas-lift bearing
Seat height adjustment	Pneumatic lift with 90 mm stroke, controlled by the visible right-side lever
Back recline	Synchro-tilt recline to 15 degrees rearward with seat-back ratio movement
Tilt tension control	Rotating knob under mechanism adjusts resistance across 5 effective turns
Tilt lock	One-position upright lock plus free-float mode through the seat-side lever
Fixed arm support	Cantilever polished loop arms provide continuous elbow support at 240 mm above seat
Mobility	Five twin-wheel casters enable rolling on hard floors and low-pile carpet
Stability system	700 mm polished five-star base distributes load beyond the seat footprint
Back support layout	Horizontal seam separates upper shoulder zone from lower lumbar zone
Occupancy posture	High-back posture support with padded seat and fixed elbow rests
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton dimensions	760 x 660 x 380 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Executive office	Suitable behind a 2000 mm executive desk where high-back support and a polished appearance are required
Manager workstation	Suitable for daily 8 hour computer and discussion tasks at standard 760 mm desk height
Meeting or board room	Suitable around conference tables requiring quiet mobility and uniform premium styling
Private consultation room	Appropriate for professional one-to-one meetings due to fixed arms and restrained black finish
Home office	Suitable for users seeking a commercial-looking chair with swivel, height adjustment, and recline
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1335-1 suitability	Office chair dimensional safety and design reference for task seating geometry
EN 1335-2 suitability	Applicable standards and test results require confirmation
EN 1335-3 suitability	Test-method reference for structural safety and durability verification
EN 1022 suitability	Stability test reference for upright and reclined seating positions
EN 12521 suitability	Furniture strength, durability, and safety reference for non-domestic seating

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1 office chair suitability	Back, seat, arm, base, caster, and fatigue-test acceptance reference for commercial task chairs
Commercial project procurement	Suitable for batch office fit-out with target testing to EN 1335 or ANSI/BIFMA X5.1

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 10357.2 suitability	Furniture mechanical test recommendation for chair seat and back strength
GB/T 10355.2 suitability	Furniture surface cold-resistant and coating test reference for painted metal parts
GB 18584 suitability	Indoor decorative material limit recommendation for formaldehyde and soluble metals

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 10357.2 suitability: Furniture mechanical test recommendation for chair seat and back strength;
2. GB/T 10355.2 suitability: Furniture surface cold-resistant and coating test reference for painted metal parts;
3. GB 18584 suitability: Indoor decorative material limit recommendation for formaldehyde and soluble metals;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · EXEC-HB-PU-ALU5-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · EXEC-HB-PU-ALU5-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · EXEC-HB-PU-ALU5-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The High-Back Black Leather Executive Swivel Chair, model EXEC-HB-PU-ALU5presents a formal executive silhouette with a tall upholstered back, generously padded seat, and polished continuous-loop arm structure. Its black smooth leather-look upholstery is paired with a polished aluminum alloy frame and five-star base, creating a restrained commercial appearance suited to premium office interiors. The two-zone back panel rises into a high-back form, while the cantilever arms provide a continuous visual line from armrest to base. The layout centers on a chrome-plated steel gas cylinder, five caster points, and a side-operated mechanism, giving the chair a balanced, conventional executive layout. Construction combines padded upholstery with metal and steel support. The seat uses a 90 mm molded polyurethane foam cushion over a molded plywood or reinforced polymer internal carrier, while the back uses polyurethane foam padding over a 20 x 2.0 mm steel tubular inner frame. Seat foam density is 45 kg/m3 and back foam density is 35 kg/m3, with foam resilience specified at 40 percent. The arm top rail is an integrated padded or leather-wrapped surface, 45 mm wide, and the chair moves on black nylon twin casters. The black upholstery is rated for 50,000 Martindale abrasion cycles, and the polished base has a static load rating of 500 kg. Recommended user weight capacity is 150 kg. Functionality is designed for daily desk work and meeting use. The chair swivels 360 degrees, and the right-side lever controls pneumatic seat-height adjustment through a 90 mm stroke. A synchro-tilt mechanism allows the back to recline 15 degrees rearward with coordinated seat and back movement. Users can adjust tilt resistance with an under-seat knob across five effective turns, select an upright lock, or use free-float mode through the seat-side lever. Fixed arm support sits 240 mm above the seat, while five twin-wheel casters support movement on hard floors and low-pile carpet. This unbranded executive chair is suitable behind executive desks, including a recommended 2.4 m executive desk, as well as manager workstations at standard desk height. It also fits boardrooms, meeting spaces, private consultation rooms, and home offices where a commercial appearance is desired. Procurement teams should note the chair is supplied as one set in two cartons, with packaged gross weight of 23 kg and reference assembly time of 40 minutes. The clear armrest width, black finish, polished metal frame, and high-back profile should be checked against desk clearance, room styling, and user requirements before ordering.

High-Back Black Leather Executive Swivel Chair Specifications
