| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 860 x 920 x 1100 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended user weight | 150 kg | |
|---|---|---|
| Net weight | 52 kg | |
| Seat foam thickness | 120 mm | |
| Back foam thickness | 100 mm | |
| Back foam density | 35 kg/m3 | |
| Seat foam density | 40 kg/m3 | |
| Foam rebound rating | 42% | |
| Static pedestal load | 300 kg | |
| Recline positions | 3 positions | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Tan leather-look surface over segmented padding | |
|---|---|---|
| Seat cushion structure | 120 mm polyurethane foam pad wrapped in upholstery | |
| Back cushion structure | Segmented horizontal and vertical foam panels | |
| Armrest padding | Soft tan upholstered arm pads with bright chrome end trim | |
| Side enclosure | Curved tan outer shell with dark brown textured lower panel | |
| Central pedestal | Chrome-plated tubular steel column | |
| Floor base | Round polished chrome-plated steel disc | |
| Recline mechanism | Concealed steel pivot and leg-rest linkage | |
| Control button | Round metal-finish side release button | |
| Dark lower side panel | Textured dark brown composite or fabric-covered panel | |
| Internal support board | 12 mm formed plywood or engineered-wood seat carrier | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Swivel movement | 360-degree swivel around the central chrome column | |
|---|---|---|
| Recline operation | Push-back backrest with side release control moving to 145 degrees | |
| Integrated leg rest | Fold-out layered footrest extends 460 mm from the seat front | |
| Return movement | Leg rest folds flush under the seat when the chair returns upright | |
| Back support zoning | Horizontal head, shoulder and lumbar cushion sections distribute upper-body pressure | |
| Arm support | Fixed padded armrests at 680 mm above floor provide forearm support during recline | |
| Side release control | Round button on the left lower panel activates the recline or footrest mechanism | |
| Pedestal stability | Wide 700 mm circular base resists tipping during swivel and recline | |
| No-clearance rotation | Single floor plate allows rotation without a separate five-star caster footprint | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Carton dimensions | 900 x 820 x 1080 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive lounge | Suitable for private offices where visitors or executives need relaxed seating | |
|---|---|---|
| Living room | Works as a reading or television recliner beside a sofa group | |
| Reception area | Suitable for upscale hospitality waiting zones with restrained decor | |
| Home study | Fits a study or library corner for long-duration reading | |
| Senior-friendly seating | Pedestal chair is appropriate where a stationary footrest and recline function are preferred over casters | |
| Hotel suite | Can be specified in executive suites or club lounges as a single lounge recliner | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
