Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 720 × 780 × 1180 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended user weight capacity | 150 kg | |
|---|---|---|
| Net weight reference | 24 kg | |
| Seat foam density | 45 kg/m3 | |
| Back foam density | 35 kg/m3 | |
| Foam rebound value | 40% | |
| Swivel bearing design | 360-degree rotational seat on central gas-lift bearing | |
| Caster rolling durability | 100000 cycles | |
| Gas-lift cycles | 100000 height-adjustment cycles | |
| Base static load | 500 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Taupe smooth leather-look upholstery with visible stitched panel seams | |
|---|---|---|
| Seat cushion | Multi-layer padded seat cushion, 120 mm thick, wrapped in taupe upholstery | |
| Backrest padding | Segmented high-back padding with integrated head pillow and lumbar channels | |
| Armrests | Upholstered fixed arm pads over curved structural side panels | |
| Five-star base | Polished chrome-finished tubular metal five-star base with five cantilever legs | |
| Gas lift and center column | Chrome-plated telescoping metal gas-lift column with black upper collar |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Pneumatic seat-height adjustment through a 60 mm lift stroke using a side-activated gas cylinder | |
|---|---|---|
| Mobility | Five-point caster base allows rolling movement on finished office floors | |
| Recline control | Side-mounted recline lever with 12-degree back tilt and lock position | |
| Posture support | High segmented back and attached head pillow support the lumbar, shoulder and neck zones |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive offices | Suitable for managers and executive users requiring a high-back padded chair for 4 to 6 hour desk sessions. | |
|---|---|---|
| Meeting and consulting rooms | Neutral taupe upholstery and polished base fit formal meeting, reception or advisory settings. |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.1 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
