Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 660 x 700 x 1260 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended user weight capacity | 150 kg | |
|---|---|---|
| Net weight reference | 23 kg | |
| Static vertical seat-load reference | 680 kg | |
| Back-rest static load reference | 136 kg | |
| Caster rolling durability target | 100,000 cycles | |
| Gas-lift durability target | 100,000 height cycles | |
| Seating capacity | 1 person | |
| Foam density target | 45 kg/m3 seat, 35 kg/m3 back | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Dark gray leather or leather-match upholstery with visible edge stitching | |
|---|---|---|
| Seat cushion | 90 mm molded polyurethane foam with a rounded waterfall front | |
| Back cushion | 70 mm contoured polyurethane foam over a tall internal support panel | |
| Internal back carrier | 12 mm molded plywood or steel-reinforced composite panel | |
| Side upholstery panels | Padded leather-wrapped panels forming continuous lateral support | |
| Seat support deck | 12 mm bent plywood or steel seat plate beneath the foam cushion | |
| Tilt mechanism | Black powder-coated steel synchro-tilt mechanism with side tension knob | |
| Gas lift | Chrome-plated steel pneumatic cylinder with 80 mm visible stroke | |
| Five-star base | Polished die-cast aluminum five-star base with tapered arms | |
| Casters | Five black nylon twin-wheel casters with hard-floor treads | |
| Stitching | Color-matched precision seam line with 8 stitches per 50 mm target | |
| Arm and side trim | Upholstered fixed arm/side enclosure without exposed plastic arm pads |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Swivel function | 360-degree swivel around the central chrome gas-lift column | |
|---|---|---|
| Height adjustment | Pneumatic seat-height adjustment through an 80 mm lift stroke | |
| Recline movement | Synchro-tilt back recline with 18-degree maximum rearward angle | |
| Tilt tension control | Side rotary knob adjusts resistance for users up to 150 kg | |
| Tilt lock | Under-seat lever locks the chair in upright or selected recline positions | |
| Mobility | Five twin-wheel casters provide omnidirectional movement on hard floors or low-pile carpet | |
| High-back support | Tall continuous back provides shoulder and upper-back support during seated work | |
| Integrated lateral support | Padded side enclosures provide fixed elbow and torso-side support without height adjustment | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Suitable behind a management desk where a high-back leather appearance and swivel mobility are required | |
|---|---|---|
| Private workstation | Suited to long-duration computer and document work for one user | |
| Meeting or supervisor room | Appropriate for senior staff meetings, reviews and private consultations | |
| Hotel-style business center | Usable in business lounges requiring mobile seating and a refined visual finish | |
| Procurement configuration | Pair with a 1600 to 1800 mm executive desk and 720 to 760 mm work-surface height | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.1 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
