PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	580 × 630 × 1000 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	160 kg
Net weight	12 kg
Stacking capacity	1 chair
Seating capacity	1 person
Seat foam density	35 kg/m3
Back foam density	30 kg/m3
Foam resilience	35%
Upholstery abrasion acceptance value	50,000 Martindale cycles
Floor glide static load per glide	50 kg
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat and back upholstery	Black upholstered surface over padded cushioning; exact leather, PU, or fabric grade requires BOM confirmation
Seat cushion core	Polyurethane foam pad with a visible thickness of 70 mm and a 35 kg/m3 procurement density target
Back cushion core	Polyurethane foam pad with a visible thickness of 65 mm and a 30 kg/m3 procurement density target
Load frame	Chrome-plated welded round steel cantilever frame using 25 mm tube as the engineering target
Arm pads	Black padded arm surfaces mounted directly to the chrome side frame
Floor glides	Black polymer non-swivel glides at four floor-contact ends

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Fixed cantilever support	Continuous chrome steel side rails flex slightly under load and return to position without springs, pivots, or casters
Fixed arm support	Padded armrests provide a 225 mm support height above the seat and do not adjust in height or width
Fixed upright posture	The non-reclining back provides a 550 mm back height above the seat for meeting and short-duration visitor use
Floor protection	Four replaceable polymer glides distribute load and allow repositioning on hard floors without embedded wheels

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Meeting and conference rooms	Use as a fixed-position guest chair around conference tables where its 450 mm seat height suits standard 760 mm desk heights
Reception and visitor waiting areas	Place in rows or pairs in reception zones where padded back support, armrests, and non-rolling glides are preferred

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office chair safety and strength	EN 1335is appropriate for static load, durability, and safety acceptance of a commercial office visitor chair
Office chair dimensions	EN 1335is appropriate for checking seat height, clearance, and dimensional consistency
Upholstered furniture flammability	BS EN 1021covers cigarette ignition resistance for upholstered seating when specified for the project
Match ignition assessment	BS EN 1021covers match-flame ignition resistance for upholstered seating when specified for the project

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Seating durability acceptance	Recommended references: ANSI/BIFMA X5.1
Office seating ergonomic reference	BIFMA G1 may be used to review seat height and basic posture dimensions, although this is a fixed non-task chair

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Formaldehyde and emissions review	GB/T 39600 applies if the chair contains wood-based panels; request batch test data before acceptance
Furniture safety review	GB 28007 applies to children's furniture only and is not a primary standard for this commercial visitor chair
Upholstered furniture durability review	GB/T 3324 may be used as a wooden furniture reference only where wooden structural parts are present; steel testing should use QB/T 2280

Standardized tender description text

This product must meet the following technical requirements:
1. Formaldehyde and emissions review: GB/T 39600 applies if the chair contains wood-based panels; request batch test data before acceptance;
2. Furniture safety review: GB 28007 applies to children's furniture only and is not a primary standard for this commercial visitor chair;
3. Upholstered furniture durability review: GB/T 3324 may be used as a wooden furniture reference only where wooden structural parts are present; steel testing should use QB/T 2280;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · FG-1787C

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · FG-1787C

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · FG-1787COpen Export Tool

Quick Actions

Post an RFQ

Product Description

The FG-1787C Black Upholstered Cantilever Visitor Chair is a fixed guest and meeting seat with a clean, linear profile. Its black upholstered seat and back contrast with a bright chrome-plated cantilever steel tube frame, creating a professional appearance suited to formal interiors. Continuous rounded side rails rise from the floor, support the seat, and extend into the back, while black padded armrests follow the frame edge. Four black polymer glides provide a simple visual termination and keep the chair without visible casters or adjustment controls. The chair is constructed as a single-person seating product with welded round steel cantilever framing, using a 25 mm tube size as the engineering target. The seat and back use black upholstered surfaces over padded cushioning. The finished seat cushion is 90 mm thick and the finished backrest padding is 70 mm thick. Their polyurethane foam cores have visible thicknesses of 70 mm and 65 mm, with procurement density targets of 35 kg/m3 for the seat and 30 kg/m3 for the back. Foam resilience is listed at 35 percent. Arm pads are mounted directly to the chrome side frame, and the non-swivel polymer glides are replaceable at the four floor-contact ends. Functionally, the chair emphasizes stable, low-mechanism seating. The cantilever rails flex slightly under load and return to position without springs, pivots, or casters. The back is non-reclining and rises 550 mm above the seat, with a 240 mm lumbar support zone for meetings and short-duration visitor use. Fixed padded armrests provide support 225 mm above the seat, and the clear width between armrests is 540 mm. The chair is rated for a recommended user weight of 160 kg and has a net weight of 12 kg. Its glides help protect hard floors and allow repositioning while avoiding the movement associated with embedded wheels. Stacking capacity is one chair, so it should be planned as a non-stacking seating option. The model is appropriate for conference and meeting rooms, particularly around standard 760 mm desks, where its 450 mm seat height supports conventional table alignment. It also works in reception and waiting zones arranged in rows or pairs, especially where arm support, padded backing, and non-rolling placement are preferred. Procurement teams should note that the product is unbranded and supplied under model FG-1787C. The exact leather, polyurethane, or fabric grade requires bill-of-materials confirmation before order finalization. Each set is packed in two cartons, with packaged gross weight of 23 kg, carton dimensions of 850 by 420 by 720 mm, and carton volume of 0.26 cubic meter. Assembly time is referenced at 40 minutes per set, and an indicative 20-foot container load is 135 sets at 85 percent space utilization.

FG-1787C Black Upholstered Cantilever Visitor Chair Specifications
