Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1640 x 2100 x 1100 mm | |
|---|---|---|
| mattress compatible size | 1530 x 2030 mm | |
| headboard height | 1100 mm | |
| headboard thickness | 180 mm | |
| side rail height | 320 mm | |
| floor to slat surface height | 170 mm | |
| leg height | 150 mm | |
| under-bed clearance | 120 mm | |
| platform overhang width | 55 mm | |
| platform overhang length (foot end) | 70 mm | |
| slat thickness | 18 mm | |
| slat spacing | 70 mm | |
| total slat count | 28 | |
| center support beam count | 2 | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| net product weight | 50 kg | |
|---|---|---|
| total static weight capacity | 363 kg | |
| noise emission level | <30 dB | |
| applicable sleeper count | 2 | |
| upholstery abrasion resistance | 30000 cycles | |
| foam padding density | 32 kg/m³ | |
| foam rebound rate | 45% | |
| edge support static load | 136 kg | |
| limited warranty period | 3 years | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| headboard upholstery | 100% polyester cream boucle fabric, looped texture | |
|---|---|---|
| headboard padding | High-density polyurethane foam, wrapped over curved frame | |
| bed base upholstery | Matching cream boucle fabric, finished stitched edge at perimeter | |
| internal frame core | 15 mm thick engineered plywood + solid pine bracing | |
| support slats | Solid kiln-dried pine wood, sanded smooth, anti-slip screw mounting | |
| support legs | Matte black powder-coated square steel block legs, 50x50 mm cross section | |
| fastening hardware | Zinc-plated steel screws, dowels, and pre-drilled connectors | |
| mattress retainer lip | Hidden fabric-covered lip at head end to prevent mattress sliding | |
| center support beams | 40 mm thick solid pine longitudinal beams, anchored to leg assemblies | |
| seam construction | Reinforced stitched seams with 8 stitches per 25 mm pitch | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| mattress support system | Solid wood slat grid, eliminates need for separate box spring | |
|---|---|---|
| assembly requirement | Flat-pack assembly with included hex key and labeled pre-drilled parts | |
| floor protection | Plastic glide inserts at base of each metal leg, prevent floor scratches | |
| cleaning compatibility | Spot clean with mild upholstery detergent and damp cloth, no machine washing | |
| noise reduction design | Slats secured with anti-slip screws, no loose rattle points during movement | |
| under-bed accessibility | 120 mm open clearance for robot vacuum access and low-profile storage | |
| positioning stability | Four-corner leg placement plus two mid-span center legs, zero wobble on level floors | |
| mattress retention | Raised upholstered lip at head and side edges prevents mattress shifting | |
| adjustment compatibility | No height adjustment, no storage lift, no recline mechanisms, fixed rigid structure | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| residential primary bedroom | Fits standard Queen mattress for two-adult use in modern or minimalist bedrooms | |
|---|---|---|
| contemporary apartment bedroom | Low-profile design suits compact spaces without overwhelming small room layouts | |
| soft neutral interior schemes | Cream boucle finish coordinates with warm neutral, Japandi, or Scandinavian decor | |
| low-profile bed preference users | Open foot end and low platform height support easy entry and exit for users | |
| vacation rental guest bedrooms | Durable boucle fabric and sturdy frame support frequent guest use | |
| upholstered bed aesthetic upgrades | Curved rounded headboard delivers soft, cloud-like visual appeal without bulky footboard |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic beds - Safety requirements and test methods, applicable to structural safety | |
|---|---|---|
| EN 1022:2005 | Domestic furniture - Seating - Determination of stability, applicable to frame stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structural performance | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture, applicable to upholstery durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural performance; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture, applicable to upholstery durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
