Automatic mm / inch conversion · Core engineering specifications
| Overall external dimensions | 2160 x 1980 x 1170 mm | |
|---|---|---|
| Headboard height (floor to top) | 1170 mm | |
| Platform height (floor to slat base) | 360 mm | |
| Recommended compatible mattress thickness | 360 mm | |
| Underbed storage compartment internal height | 280 mm | |
| Footboard pull handle length | 180 mm | |
| Support leg height | 180 mm | |
| Slat width | 70 mm | |
| Slat spacing between adjacent slats | 75 mm | |
| Mattress retainer lip height at head end | 50 mm | |
| Side rail thickness (upholstered) | 80 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity (frame + users + mattress) | 454 kg | |
|---|---|---|
| Underbed storage compartment load capacity | 100 kg | |
| Net product weight | 68 kg | |
| Recommended maximum user count | 2 adults | |
| Fabric upholstery abrasion resistance (Martindale) | 30000 cycles | |
| Hydraulic lift mechanism cycle rating | 10000 open/close cycles | |
| Noise emission during use (mattress load applied) | ≤30 dB | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Light blue woven fabric with tight weave | |
|---|---|---|
| Headboard internal padding | 30mm high-density polyurethane foam | |
| Internal frame core | 1.2mm thick powder-coated rectangular steel tube | |
| Support slats | 15mm thick laminated plywood slats | |
| Support legs | Matte black powder-coated tapered steel legs | |
| Storage lift mechanism | Dual-side steel hydraulic gas struts | |
| Contact pads between metal and wood | EVA anti-slip, noise-dampening felt pads | |
| Footboard pull handle | Matte black steel recessed pull bar | |
| Side rail and footboard upholstery | Matching light blue woven fabric over padded core | |
| Hardware connectors | Zinc-plated steel bolts, barrel nuts and corner brackets | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Underbed storage access | Foot-end pull handle activates dual gas struts to lift platform 45 degrees | |
|---|---|---|
| Headboard design | Split dual-cushion button-tufted padded surface with lumbar support zone | |
| Slat support system | 13 evenly spaced plywood slats with central support rail | |
| Mattress retention | Integrated head-end lip prevents forward mattress sliding during lift operation | |
| Noise reduction design | EVA/felt pads at all metal-wood and metal-metal contact points | |
| Mattress compatibility | Supports memory foam, latex, hybrid and innerspring mattresses | |
| Cleaning and maintenance | Spot-cleanable fabric surface, wipe with dry or lightly damp cloth | |
| Assembly requirement | Flat-pack assembly with included Allen key and hardware | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom | Fits standard king size mattress for two-adult primary bedroom use | |
|---|---|---|
| Small urban apartment bedrooms | Lift-up underbed storage maximizes floor space for linens and off-season clothing | |
| Guest bedroom use | Neutral color and durable construction support regular guest occupancy | |
| Matching bedroom set configuration | Pairs with coordinating 2-drawer upholstered nightstands for cohesive design | |
| Seated in-bed use | Tufted padded headboard provides back support for reading or screen use in bed |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1022:2005 | Domestic furniture - Seating and beds - Determination of stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and slat structural performance | |
|---|---|---|
| GB 20400-2006 | Leather/fur safety limits, applicable if using leather/faux leather upholstery material | |
| GB/T 1952.2-2011 | Spring and upholstered mattress support furniture safety requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and slat structural performance; 2. GB 20400-2006: Leather/fur safety limits, applicable if using leather/faux leather upholstery material; 3. GB/T 1952.2-2011: Spring and upholstered mattress support furniture safety requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
