Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (with side nightstands) | 3353 x 2210 x 1118 mm | |
|---|---|---|
| Sleeping surface (king size) | 1930 x 2030 mm | |
| Headboard height | 1118 mm | |
| Bed frame platform height (floor to slat top) | 305 mm | |
| Recommended mattress thickness | 305 mm | |
| Under-bed clearance (floor to frame bottom) | 203 mm | |
| Side nightstand shelf projection from headboard | 406 mm | |
| Glass nightstand shelf height above mattress | 203 mm | |
| Walnut storage tier height above floor | 356 mm | |
| Reading lamp mounting height above mattress | 762 mm | |
| Slat width | 70 mm | |
| Slat spacing | 76 mm | |
| Leg diameter (chrome support) | 32 mm | |
| Lampshade dimensions | 178 x 254 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 363 kg | |
|---|---|---|
| Product net weight | 70 kg | |
| Number of occupants supported | 2 | |
| Nightstand shelf static load per unit | 15 kg | |
| Center support leg count | 3 | |
| Slat total count | 28 | |
| Noise reduction fastener rating | 10000 cycles | |
| Wall mounting bracket load capacity per side | 25 kg | |
| LED reading lamp lumen output per unit | 350 lm | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard outer layer | Woven beige linen blend upholstery | |
|---|---|---|
| Headboard padding | 25mm high-density polyurethane foam | |
| Internal bed frame core | 18mm plywood and MDF engineered wood | |
| Bed base perimeter frame | Polished chrome-plated steel tube | |
| Lower nightstand storage tiers | Walnut veneer over MDF with matte finish | |
| Upper nightstand shelves | 10mm frosted tempered glass | |
| Swing-arm hardware | Polished chrome-plated solid steel | |
| Support slats | 12mm solid poplar wood | |
| Reading lamp shades | Pleated off-white linen fabric | |
| Connector hardware | Zinc-plated steel bolts and cam locks | |
| Anti-slip mattress pad | 3mm non-woven polyester fabric | |
| Foot caps | Non-marking black TPE plastic |
Adjustment / rotation / tilt / mobility / storage features
| Swing-arm nightstand adjustment | 180° horizontal rotation for custom bedside positioning | |
|---|---|---|
| Integrated reading lamp operation | 350lm warm white LED output with independent on/off switch per side | |
| Mattress support system | Wood slat platform with center bracing, no box spring required | |
| Stacked nightstand storage | Two-tier storage per side: upper glass shelf for drinks/phones, lower walnut tier for books/accessories | |
| Noise reduction feature | Velcro-fixed slats to eliminate frame creaking during movement | |
| Under-bed access | 203mm open clearance for robotic vacuum cleaning and low-profile storage items | |
| Wall anchor system | Included wall attachment brackets to prevent headboard tipping | |
| Assembly requirement | Two-person adult assembly with included hex key and hardware | |
| Lampshade orientation adjustment | 30° vertical tilt for targeted reading light direction | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Primary residential bedrooms | |
|---|---|---|
| Target user group | Adult consumers seeking all-in-one bedroom furniture without separate nightstands | |
| Recommended room size | Minimum 3.6m x 4.0m bedroom | |
| Style compatibility | Modern, contemporary, and minimalist bedroom interiors | |
| Recommended complementary furniture | Low-profile dressers and wardrobes in walnut or chrome finishes | |
| Practical use benefit | Ideal for compact primary bedrooms where space for separate nightstands is limited | |
| Installation requirement | Headboard mounted against finished wall with power access nearby |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses: safety requirements, applicable to structural stability | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - Seating and beds: determination of stability, applicable to tip-over prevention | |
| EN 12520:2015 | Furniture - Strength, durability and safety: requirements for domestic seating, applicable for edge load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood frame components | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials: limit of harmful substances in wood furniture, applicable to veneer and board components | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture: beds, applicable to upholstered headboard and platform assembly |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood frame components; 2. GB 18584-2001: Indoor decorating and refurbishing materials: limit of harmful substances in wood furniture, applicable to veneer and board components; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture: beds, applicable to upholstered headboard and platform assembly; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
