Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (queen size) | 1702 x 2235 x 1473 mm | |
|---|---|---|
| Headboard total height | 1473 mm | |
| Headboard width | 1702 mm | |
| Headboard padding thickness | 114 mm | |
| Side rail height above slats | 305 mm | |
| Floor to slat support height | 152 mm | |
| Underbed clearance | 201 mm | |
| Slat length | 1524 mm | |
| Slat width | 70 mm | |
| Slat thickness | 18 mm | |
| Slat spacing gap | 76 mm | |
| Center support leg diameter | 20 mm | |
| Recommended mattress thickness | 381 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 454 kg | |
|---|---|---|
| Product net weight | 55 kg | |
| Number of support slats | 18 | |
| Number of center support legs | 3 | |
| Number of corner support legs | 4 | |
| Seam stitch pitch | 8 stitches per 25 mm | |
| Foam padding density | 32 kg/m³ | |
| Foam rebound rate | 55% | |
| Expected daily use service life | 10 years | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Dark brown faux leather with matte finish | |
|---|---|---|
| Headboard padding | High-density polyurethane foam | |
| Side rail upholstery | Matching dark brown faux leather with vertical channel stitching | |
| Foot rail upholstery | Matching dark brown faux leather with vertical channel stitching | |
| Internal frame | Engineered wood (plywood/MDF) structural core | |
| Support slats | Solid plywood slats with sanded smooth surface | |
| Support legs | Matte dark gray/black cylindrical steel legs | |
| Center support beam | Rectangular steel tube beam | |
| Hardware connectors | Zinc-plated steel bolts, barrel nuts and washers | |
| Anti-slip slat pads | EVA foam pads between slats and frame | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Box spring requirement | No box spring required | |
|---|---|---|
| Mattress retention | Upholstered side rails prevent lateral mattress shift | |
| Noise reduction | EVA slat isolation pads minimize metal-wood contact squeak | |
| Knockdown assembly | Flat-pack assembly with included hardware and instructions | |
| Underbed access | 201mm underbed clearance allows robotic vacuum access | |
| Wingback headboard support | Integrated side wings provide padded lateral back support for sitting in bed | |
| Surface care | Wipe-clean faux leather surface resists minor spills and stains | |
| Weight distribution | Center steel beam and 3 mid-legs evenly distribute mattress and user weight | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms | |
|---|---|---|
| Secondary application space | Guest bedrooms | |
| Target user group | Adult residential users | |
| Style compatibility | Modern, contemporary, minimalist interior schemes | |
| Recommended configuration | Pair with 300 mm thick memory foam or hybrid mattress | |
| Care and maintenance | Regular vacuum of upholstery seams, wipe spills immediately with soft damp cloth | |
| Placement requirement | Position with 600mm clear space on both sides and foot of bed |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture – Beds and mattresses – Safety requirements and test methods | |
|---|---|---|
| EN 1022:2018 | Domestic furniture – Seating/bed stability test for structural safety | |
| EN 1334:2000 | Bed and mattress strength and durability testing for residential use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame integrity | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture, applicable to formaldehyde emission control | |
| GB/T 1952.2-2011 | Spring soft mattress support surface compatibility for bed frames | |
| GB/T 2828.1-2012 | Inspection sampling procedures for incoming hardware and component quality checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame integrity; 2. GB 18584-2001: Limit of harmful substances in wood furniture, applicable to formaldehyde emission control; 3. GB/T 1952.2-2011: Spring soft mattress support surface compatibility for bed frames; 4. GB/T 2828.1-2012: Inspection sampling procedures for incoming hardware and component quality checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
