| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions (queen size) | 1626 x 2240 x 1135 mm | |
|---|---|---|
| floor to slat support platform height | 152 mm | |
| recommended compatible mattress thickness | 305 mm | |
| headboard top height above platform | 983 mm | |
| side rail thickness (upholstered) | 203 mm | |
| wraparound headboard side extension length | 762 mm | |
| slat count (queen size) | 28 | |
| slat thickness | 19 mm | |
| slat spacing between adjacent slats | 70 mm | |
| center support beam count | 3 | |
| upholstery padding thickness on headboard panels | 51 mm | |
| underbed clearance (fully upholstered base) | 0 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| total static weight capacity | 318 kg | |
|---|---|---|
| product net weight | 77 kg | |
| maximum recommended mattress weight | 68 kg | |
| upholstery abrasion resistance (Martindale) | 30000 cycles | |
| foam density (padding) | 28 kg/m³ | |
| foam rebound rate | 45% | |
| expected structural service life | 10 years | |
| edge support static load rating | 113 kg | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| outer upholstery fabric | 100% polyester textured boucle, off-white color | |
|---|---|---|
| seam finish | Dark contrast piping along all curved panel seams | |
| frame core structure | Plywood and manufactured wood panel internal frame | |
| padding fill | High-resilience polyurethane foam on all upholstered panels | |
| mattress support slats | Solid kiln-dried pine wood slats, anti-slip screw mounting | |
| support framework | Powder-coated steel center support beams and hardware | |
| connector hardware | Zinc-plated steel bolts, dowels and pre-drilled assembly points | |
| base bottom layer | Non-woven fabric dust cover under upholstered base | |
| fabric surface treatment | Stain-resistant topical finish for spot cleaning | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| mattress support function | Solid slat platform eliminates need for separate box spring | |
|---|---|---|
| anti-slip mattress retention | Anti-slip slat surface and recessed platform lip prevents mattress shifting | |
| safety edge design | Fully rounded padded edges on all frame corners reduces impact injury risk | |
| assembly mechanism | Knock-down flat-pack assembly with pre-drilled holes and included hardware | |
| underbed design | Fully enclosed upholstered base with no open underbed storage or leg gaps | |
| headboard function | Fixed padded wraparound headboard provides back support for seated bed use | |
| adjustable base compatibility | Slat system compatible with zero-clearance adjustable mattress bases | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| residential primary bedroom use | Suitable for queen size bedroom layouts, modern minimalist and contemporary decor styles | |
|---|---|---|
| apartment and small space installation | Low profile and enclosed base works for compact urban living spaces | |
| low-fuss household use | Fully enclosed base eliminates underbed dust accumulation for easy maintenance | |
| residential guest room configuration | Soft curved design creates welcoming guest accommodation space | |
| contemporary interior design projects | Boucle texture and contrast piping fits modern curated residential interiors | |
| households with children | Rounded padded edges reduce injury risk from accidental contact with frame |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture - Ignitability assessment for smouldering cigarette source |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame components | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to panel and finish materials | |
| GB/T 1952.2-2011 | Technical requirements for upholstered furniture mattresses and bed bases |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame components; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to panel and finish materials; 3. GB/T 1952.2-2011: Technical requirements for upholstered furniture mattresses and bed bases; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
