Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (mattress 1800x2000mm king size) | 2290 x 1880 x 1100 mm | |
|---|---|---|
| Headboard total height | 1100 mm | |
| Sleeping surface height (platform top) | 360 mm | |
| Under-bed clearance (floor to rail bottom) | 240 mm | |
| Headboard panel thickness (padded) | 120 mm | |
| Side rail height above slat surface | 200 mm | |
| Recommended mattress thickness | 300 mm | |
| Individual slat width | 70 mm | |
| Slat thickness | 18 mm | |
| Slat spacing between adjacent slats | 70 mm | |
| Total slat count (king size) | 26 | |
| Center support leg count | 3 | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm |
Net weight / load capacity / users / durability
| Total static load capacity (sleeping surface) | 500 kg | |
|---|---|---|
| Product net weight | 64 kg | |
| Per-leg static load rating | 125 kg | |
| Foam padding density (headboard) | 35 kg/m³ | |
| Foam indentation load deflection (headboard) | 40 | |
| Upholstery abrasion resistance (Martindale) | 30000 cycles | |
| Structural joint cycle rating (normal use) | 10000 cycles | |
| Noise reduction rating (slat contact) | <30 dB | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard and side rail upholstery | Teal faux leather (PU leather) with smooth matte finish | |
|---|---|---|
| Headboard padding | High-density polyurethane foam core | |
| Internal bed frame structure | Engineered wood (particleboard + plywood) frame | |
| Mattress support slats | 18mm thick poplar plywood slats | |
| Support legs | Gold powder-coated carbon steel tapered legs | |
| Slat connecting hardware | Zinc-plated steel bolts and barrel nuts | |
| Mute strips between slats and rails | 3mm thick EVA foam strips | |
| Leg foot pads | Non-slip TPE rubber pads | |
| Seam stitching | Polyester heavy-duty thread with 8 stitches per 30mm | |
| Surface finish coating (metal legs) | Baked gold powder coat | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Curved plywood slat platform, no box spring required | |
|---|---|---|
| Mattress retention design | Raised side rails and integrated headboard lip | |
| Under-bed access | 240mm floor clearance for robotic vacuum cleaning | |
| Headboard function | Padded wingback split-panel design for seated back support | |
| Assembly structure | Knock-down design with bolted rail-to-headboard connections | |
| Surface maintenance | Wipe-clean faux leather upholstery, stain-resistant surface | |
| Floor protection | Non-slip rubber foot pads on all support legs | |
| Weight distribution | 3 center support legs along the frame midline | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary residential use | Master bedroom king-size sleeping configuration | |
|---|---|---|
| Secondary use case | Upscale guest bedroom furnishing | |
| Compatible interior styles | Modern light luxury, Nordic minimalist, contemporary teal-themed rooms | |
| Recommended pairing furniture | Matching 2-drawer teal nightstands with gold legs as shown | |
| User group suitability | Adult users including couples, users preferring low-profile bed access | |
| Cleaning adaptability | Bedrooms using robotic vacuum cleaners for floor maintenance |
EU Market Access Requirements* EN Standards
| EN 1725:1998 Domestic furniture - Beds and mattresses - Safety requirements and test methods | Applicable for structural safety and edge performanceAcceptancereference |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for wood frame structural integrity and finish qualityAcceptancereference | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde emission limit from wood components | |
| GB/T 16799-2008 Polyurethane leather for furniture | Applicable for faux leather upholstery performance and safety requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for wood frame structural integrity and finish qualityAcceptancereference; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde emission limit from wood components; 3. GB/T 16799-2008 Polyurethane leather for furniture: Applicable for faux leather upholstery performance and safety requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
