Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (Queen size) | 1830 x 2140 x 1330 mm | |
|---|---|---|
| Headboard height (floor to top) | 1330 mm | |
| Sleeping surface height (floor to slat top) | 350 mm | |
| Underbed storage compartment internal depth | 300 mm | |
| Slat width | 70 mm | |
| Slat thickness | 25 mm | |
| Slat spacing | 75 mm | |
| Footboard height (floor to frame top) | 380 mm | |
| Tapered metal leg height | 150 mm | |
| Headboard wing extension width per side | 100 mm | |
| Side pull handle length | 120 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 454 kg | |
|---|---|---|
| Underbed storage load capacity | 100 kg | |
| Number of supported sleepers | 2 | |
| Anti-squeak performance cycle rating | 10000 motion cycles | |
| Upholstery abrasion resistance | 30000 double rubs | |
| Product net weight | 68 kg | |
| Recommended mattress thickness | 300 mm | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery fabric | Woven linen-look performance fabric | |
|---|---|---|
| Headboard padding | 40mm thick high-density polyurethane foam | |
| Inner support frame | 18mm thick E0-grade engineered plywood with steel bracing | |
| Support slats | Solid pine wood slat roll kit | |
| Bed legs | Matte black powder-coated tapered steel legs | |
| Storage compartment panels | 15mm thick MDF with fabric wrapping | |
| Storage pull handle | Black matte recessed metal pull | |
| Anti-slip slat strips | EVA foam padding on slat contact points | |
| Hardware connectors | Zinc-plated steel bolts and dowels | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Underbed storage operation | Side-pull roll-out storage compartment with smooth metal glides | |
|---|---|---|
| Mattress support system | Pre-assembled slat roll with center support rail, no box spring required | |
| Seated back support | Wingback upholstered headboard with padded segments for upright reading support | |
| Floor leveling adjustment | Threaded adjustable feet on each leg to compensate for uneven floors | |
| Headboard attachment | Bolt-on headboard with pre-drilled mounting holes for variable mattress height | |
| Storage glide load rating | 50kg per side, full-extension glides for complete compartment access | |
| Noise damping | EVA anti-slip strips between slats and frame eliminate metal-on-metal squeak | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary residential use | Master or guest bedrooms in modern, light luxury styled homes | |
|---|---|---|
| Target user group | Adult users seeking concealed storage without bulky bedroom furniture | |
| Recommended supporting furniture | Matching two-drawer nightstands placed symmetrically on both sides | |
| Space requirement | Minimum 3000 x 3300 mm bedroom floor area to allow side access to storage | |
| Recommended mattress type | All-foam, hybrid, or innerspring mattresses 300 mm thick | |
| Style compatibility | Pairs with light wood flooring, neutral wall colors, and soft textile decor |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture beds and mattresses safety requirements, applicable to structural strength verification | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability smouldering cigarette test, applicable to upholstery fabric safety |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to inner frame and panel components | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to formaldehyde emission verification | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture beds, applicable to structural stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner frame and panel components; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to formaldehyde emission verification; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture beds, applicable to structural stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
